- Part number
- 1SCA022627R6860
- Model no
- OFAF3H425
- CE
- RoHS
ABB 1SCA022627R6860 OFAF3H425 HRC Fuselink 425A 500VAC/250VDC 120kA OFAF Series
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 355 | 1SCA022627R6190 | In stock | $12.40 | |
| 400 | 1SCA022627R6270 | In stock | $12.40 | |
| 425 | 1SCA022627R6860This part | Low stock | $26.17 | |
| 630 | 1SCA022627R7160 | Low stock | $26.17 | |
| 800 | 1SCA022627R7240 | In stock | $54.76 |
Description
About the OFAF3H425
About the OFAF3H425
The ABB OFAF3H425 (SKU: 1SCA022627R6860) is a high-rupturing-capacity (HRC) fuselink rated at 425A and 500VAC / 250VDC, delivering exceptional short-circuit protection with a breaking capacity of 120 kA AC and 80 kA DC. Part of ABB's trusted OFAF series, this fuselink is engineered for demanding industrial applications where reliable overcurrent protection is critical in switchgear, motor circuits, and power distribution panels.
Certifications & Standards
- RoHS: Compliant with EU Restriction of Hazardous Substances Directive
- REACH: Compliant with EU REACH chemical safety regulation
- EU Directive 2011/65/EU & Amendment 2015/863: Fully compliant with European RoHS legislation and its amendment
- IEC 60269: Manufactured in accordance with IEC 60269 international standard for low-voltage fuses
- CE: Carries CE marking for conformity with applicable EU directives
- WEEE: Registered and compliant with Waste Electrical and Electronic Equipment Directive
Applications & Use Cases
- Short-circuit and overcurrent protection in industrial switchgear panels
- Motor feeder circuit protection in manufacturing and process automation Motor circuit protection in control panels and MCC (Motor Control Centres)
- Power distribution boards in commercial and heavy industrial installations
- Protection of busbars, transformers, and cable feeders up to 500VAC
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 4
| Product Net Width | 70 mm |
|---|---|
| Product Net Height | 150 mm |
| Product Net Depth / Length | 84 mm |
| Product Net Weight | 1 kg |
Technical 8
| Fuse Size | NH3 |
|---|---|
| Fuse System | DIN |
| Fuse Type | gG |
| Power Loss | at Rated Current 34 W, Total 34 W |
| Rated Current (In) | 425 A |
| Rated Voltage (Ur) | 500 V |
| Standards | IEC 60269 |
| Utilization Category | gL/gG (Cable protection/equipment protection) |
Show all 39 specifications ↓ Show less ↑26 more values in Identification, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA022627R6860 |
|---|---|
| Type designation | OFAF3H425 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019206141 |
| ETIM class | EC000055 |
| eCl@ss | 27142005 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85361090 |
| Country of Origin | Hungary |
External Classifications and Standards 4
| ETIM 10 | EC000055 - Knife blade fuse |
|---|---|
| UNSPSC | 39121600 |
| eClass | V11.1 : 27142005 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Logistics 10
| Package Level 1 Units | box 1 piece |
|---|---|
| Package Level 1 Width | 70 mm |
| Package Level 1 Depth / Length | 150 mm |
| Package Level 1 Height | 84 mm |
| Package Level 1 Gross Weight | 1.05 kg |
| Package Level 1 EAN | 6417019206141 |
| Shipping weight | 1.05 kg |
| Ships from | Türkiye |
| Dispatch | 17 Nov |
| Stock | Low stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SCA022627R6860
No documents are on file for this part yet.
Ask us for the datasheet
Other ratings
All 25 ratings in OFAF
| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 2 A | 1SCA022627R0230 | OFAF000H2 | In stock | $16.91 | |||
| 4 A | 1SCA022627R0310 | OFAF000H4 | In stock | $10.32 | |||
| 6 A | 1SCA022627R0400 | OFAF000H6 | In stock | $10.32 | |||
| 10 A | 1SCA022627R0580 | OFAF000H10 | In stock | $10.32 | |||
| 16 A | 1SCA022627R0660 | OFAF000H16 | In stock | $10.32 | |||
| 20 A | 1SCA022627R0740 | OFAF000H20 | In stock | $10.32 | |||
| 25 A | 1SCA022627R0820 | OFAF000H25 | Low stock | $10.32 | |||
| 32 A | 1SCA022627R0910 | OFAF000H32 | In stock | $10.32 | |||
| 35 A | 1SCA022627R1040 | OFAF000H35 | In stock | $10.32 | |||
| 40 A | 1SCA022627R1120 | OFAF000H40 | In stock | $10.32 | |||
| 50 A | 1SCA022627R1210 | OFAF000H50 | In stock | $10.32 | |||
| 63 A | 1SCA022627R1390 | OFAF000H63 | In stock | $10.32 | |||
| 80 A | 1SCA022627R1470 | OFAF000H80 | In stock | $10.32 | |||
| 100 A | 1SCA022627R1550 | OFAF000H100 | In stock | $10.32 | |||
| 125 A | 1SCA022627R1630 | OFAF00H125 | In stock | $14.11 | |||
| 160 A | 1SCA022627R1710 | OFAF00H160 | In stock | $14.11 | |||
| 200 A | 1SCA022627R4490 | OFAF1H200 | In stock | $9.99 | |||
| 224 A | 1SCA022627R4570 | OFAF1H224 | Critical stock | $9.99 | |||
| 250 A | 1SCA022627R4650 | OFAF1H250 | In stock | $9.99 | |||
| 300 A | 1SCA022627R5970 | OFAF2H300 | In stock | $12.40 | |||
| 355 A | 1SCA022627R6190 | OFAF2H355 | In stock | $12.40 | |||
| 400 A | 1SCA022627R6270 | OFAF2H400 | In stock | $12.40 | |||
| 425 A | 1SCA022627R6860 This part | OFAF3H425 | Low stock | $26.17 | |||
| 630 A | 1SCA022627R7160 | OFAF3H630 | Low stock | $26.17 | |||
| 800 A | 1SCA022627R7240 | OFAF3H800 | In stock | $54.76 |
Certifications
Certifications and standards
- CE
- RoHS
- IEC 60269
Quick answers
Questions about the OFAF3H425
What is the rated current of OFAF3H425?
The rated current of OFAF3H425 is 425 A.
Which supply voltage is OFAF3H425 rated for?
The rated operational voltage of OFAF3H425 is 500 – 250 V DC.
What is the HS code of OFAF3H425 for customs?
The tariff (HS) code on file for OFAF3H425 is 85361090.
What is the EAN of OFAF3H425?
The EAN (GTIN) of OFAF3H425 is 6417019206141.
Where does OFAF3H425 ship from, and how fast?
OFAF3H425 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
Reviews
Customer reviews
Series
ABB OFAF
- Brand
- ABB
- Series
- OFAF
- Rated current
- 2–800 A
- Supply voltage
- 500 – 250 V DC
- Ratings listed
- 25
