ABB 1SCA022627R4570 OFAF1H224 224A 500VAC/250VDC 120kA HRC Fuselink (HRC Fuse Link)
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 160 | 1SCA022627R1710 | In stock | $14.11 | |
| 200 | 1SCA022627R4490 | In stock | $9.99 | |
| 224 | 1SCA022627R4570This part | Critical stock | $9.99 | |
| 250 | 1SCA022627R4650 | In stock | $9.99 | |
| 300 | 1SCA022627R5970 | In stock | $12.40 |
Description
About the OFAF1H224
About the OFAF1H224
The ABB OFAF1H224 HRC fuse link (SKU 1SCA022627R4570) is a high-rupturing-capacity fuselink rated at 224A and 500VAC / 250VDC, delivering a breaking capacity of 120 kA AC and 80 kA DC. Part of ABB's OFAF series, the OFAF1H224 is engineered for reliable short-circuit and overcurrent protection in industrial power distribution systems, control panels, and motor branch circuits.
Certifications & Standards
- IEC 60269: International standard for low-voltage fuses, confirming compliance with performance and safety requirements for HRC fuse links
- CE: Conformité Européenne marking confirming compliance with applicable EU directives and harmonised standards
- RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU limiting hazardous materials in electrical equipment
- EU Directive 2011/65/EU: RoHS Directive restricting the use of specific hazardous substances in electrical and electronic equipment
- Amendment 2015/863: Delegates Directive amending Annex II to Directive 2011/65/EU, expanding the restricted substances list
- REACH: Registration, Evaluation, Authorisation and Restriction of Chemicals — confirms product substance compliance under EU REACH regulation
- WEEE: Waste Electrical and Electronic Equipment Directive compliance, ensuring proper end-of-life recycling and disposal obligations are met
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 4
| Product Net Width | 40 mm |
|---|---|
| Product Net Height | 135 mm |
| Product Net Depth / Length | 65 mm |
| Product Net Weight | 0.4 kg |
Technical 8
| Fuse Size | NH1 |
|---|---|
| Fuse System | DIN |
| Fuse Type | gG |
| Power Loss | at Rated Current 19 W, Total 19 W |
| Rated Current (In) | 224 A |
| Rated Voltage (Ur) | 500 V |
| Standards | IEC 60269 |
| Utilization Category | gL/gG (Cable protection/equipment protection) |
Show all 40 specifications ↓ Show less ↑27 more values in Identification, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA022627R4570 |
|---|---|
| Type designation | OFAF1H224 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019205847 |
| ETIM class | EC000055 |
| eCl@ss | 27142005 |
| Minimum Order Quantity | 3 piece |
| Customs Tariff Number | 85361090 |
| Country of Origin | Hungary |
External Classifications and Standards 5
| ETIM 10 | EC000055 - Knife blade fuse |
|---|---|
| UNSPSC | 39121600 |
| eClass | V11.1 : 27142005 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| E-Number (Sweden) | 2040128 |
Logistics 10
| Package Level 1 Units | box 3 piece |
|---|---|
| Package Level 1 Width | 40 mm |
| Package Level 1 Depth / Length | 135 mm |
| Package Level 1 Height | 65 mm |
| Package Level 1 Gross Weight | 1.26 kg |
| Package Level 1 EAN | 6417019205847 |
| Shipping weight | 1.26 kg |
| Ships from | Türkiye |
| Dispatch | 17 Nov |
| Stock | Critical stock |
Source: manufacturer data · Last verified: 30 Oct 2026
