- Part number
- 1SCA022627R5970
- Model no
- OFAF2H300
- CE
- RoHS
ABB 1SCA022627R5970 OFAF2H300 300A 500VAC/250VDC 120kA HRC Fuselink (HRC Fuse Link)
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 224 | 1SCA022627R4570 | Critical stock | $9.99 | |
| 250 | 1SCA022627R4650 | In stock | $9.99 | |
| 300 | 1SCA022627R5970This part | In stock | $12.40 | |
| 355 | 1SCA022627R6190 | In stock | $12.40 | |
| 400 | 1SCA022627R6270 | In stock | $12.40 |
Description
About the OFAF2H300
About the OFAF2H300
The ABB OFAF2H300 (SKU: 1SCA022627R5970) is a 300A HRC (High Rupturing Capacity) fuselink rated at 500VAC / 250VDC, delivering a breaking capacity of 120 kA AC and 80 kA DC. Part of ABB's OFAF series, this industrial-grade fuse link is engineered for robust overcurrent and short-circuit protection in demanding power distribution and industrial control panel applications.
Certifications & Standards
- IEC 60269: Compliant with the international standard for low-voltage fuses, ensuring reliable overcurrent protection performance
- CE: Meets European conformity requirements for electrical equipment placed on the EU market
- RoHS: Compliant with EU Directive 2011/65/EU on the restriction of hazardous substances in electrical and electronic equipment
- REACH: Compliant with EU REACH regulation (EC No 1907/2006) for chemical substance safety
- EU Directive 2011/65/EU: Restriction of hazardous substances (RoHS) directive compliance confirmed
- Amendment 2015/863: Compliant with the updated RoHS annex listing additional restricted substances
- WEEE: Compliant with the EU Waste Electrical and Electronic Equipment directive for end-of-life product management
Applications & Use Cases
- Short-circuit and overcurrent protection in low-voltage power distribution panels
- Industrial motor feeder and branch circuit protection up to 300A Control panel and switchgear assemblies requiring IEC 60269-compliant fusegear
- DC bus protection in renewable energy and industrial drive systems (rated to 250VDC)
- Replacement fuselinks in existing ABB OFAF series fusegear installations
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 4
| Product Net Width | 51 mm |
|---|---|
| Product Net Height | 150 mm |
| Product Net Depth / Length | 72 mm |
| Product Net Weight | 0.63 kg |
Technical 8
| Fuse Size | NH2 |
|---|---|
| Fuse System | DIN |
| Fuse Type | gG |
| Power Loss | at Rated Current 21 W, Total 21 W |
| Rated Current (In) | 300 A |
| Rated Voltage (Ur) | 500 V |
| Standards | IEC 60269 |
| Utilization Category | gL/gG (Cable protection/equipment protection) |
Show all 39 specifications ↓ Show less ↑26 more values in Identification, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA022627R5970 |
|---|---|
| Type designation | OFAF2H300 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019206004 |
| ETIM class | EC000055 |
| eCl@ss | 27142005 |
| Minimum Order Quantity | 3 piece |
| Customs Tariff Number | 85361090 |
| Country of Origin | Hungary |
External Classifications and Standards 4
| ETIM 10 | EC000055 - Knife blade fuse |
|---|---|
| UNSPSC | 39121600 |
| eClass | V11.1 : 27142005 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Logistics 10
| Package Level 1 Units | box 3 piece |
|---|---|
| Package Level 1 Width | 51 mm |
| Package Level 1 Depth / Length | 150 mm |
| Package Level 1 Height | 72 mm |
| Package Level 1 Gross Weight | 1.9845 kg |
| Package Level 1 EAN | 6417019206004 |
| Shipping weight | 1.984 kg |
| Ships from | Türkiye |
| Dispatch | 17 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SCA022627R5970
No documents are on file for this part yet.
Ask us for the datasheet
Other ratings
All 25 ratings in OFAF
| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 2 A | 1SCA022627R0230 | OFAF000H2 | In stock | $16.91 | |||
| 4 A | 1SCA022627R0310 | OFAF000H4 | In stock | $10.32 | |||
| 6 A | 1SCA022627R0400 | OFAF000H6 | In stock | $10.32 | |||
| 10 A | 1SCA022627R0580 | OFAF000H10 | In stock | $10.32 | |||
| 16 A | 1SCA022627R0660 | OFAF000H16 | In stock | $10.32 | |||
| 20 A | 1SCA022627R0740 | OFAF000H20 | In stock | $10.32 | |||
| 25 A | 1SCA022627R0820 | OFAF000H25 | Low stock | $10.32 | |||
| 32 A | 1SCA022627R0910 | OFAF000H32 | In stock | $10.32 | |||
| 35 A | 1SCA022627R1040 | OFAF000H35 | In stock | $10.32 | |||
| 40 A | 1SCA022627R1120 | OFAF000H40 | In stock | $10.32 | |||
| 50 A | 1SCA022627R1210 | OFAF000H50 | In stock | $10.32 | |||
| 63 A | 1SCA022627R1390 | OFAF000H63 | In stock | $10.32 | |||
| 80 A | 1SCA022627R1470 | OFAF000H80 | In stock | $10.32 | |||
| 100 A | 1SCA022627R1550 | OFAF000H100 | In stock | $10.32 | |||
| 125 A | 1SCA022627R1630 | OFAF00H125 | In stock | $14.11 | |||
| 160 A | 1SCA022627R1710 | OFAF00H160 | In stock | $14.11 | |||
| 200 A | 1SCA022627R4490 | OFAF1H200 | In stock | $9.99 | |||
| 224 A | 1SCA022627R4570 | OFAF1H224 | Critical stock | $9.99 | |||
| 250 A | 1SCA022627R4650 | OFAF1H250 | In stock | $9.99 | |||
| 300 A | 1SCA022627R5970 This part | OFAF2H300 | In stock | $12.40 | |||
| 355 A | 1SCA022627R6190 | OFAF2H355 | In stock | $12.40 | |||
| 400 A | 1SCA022627R6270 | OFAF2H400 | In stock | $12.40 | |||
| 425 A | 1SCA022627R6860 | OFAF3H425 | Low stock | $26.17 | |||
| 630 A | 1SCA022627R7160 | OFAF3H630 | Low stock | $26.17 | |||
| 800 A | 1SCA022627R7240 | OFAF3H800 | In stock | $54.76 |
Certifications
Certifications and standards
- CE
- RoHS
- IEC 60269
Quick answers
Questions about the OFAF2H300
What is the rated current of OFAF2H300?
The rated current of OFAF2H300 is 300 A.
Which supply voltage is OFAF2H300 rated for?
The rated operational voltage of OFAF2H300 is 500 – 250 V DC.
What is the HS code of OFAF2H300 for customs?
The tariff (HS) code on file for OFAF2H300 is 85361090.
What is the EAN of OFAF2H300?
The EAN (GTIN) of OFAF2H300 is 6417019206004.
Where does OFAF2H300 ship from, and how fast?
OFAF2H300 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
Reviews
Customer reviews
Series
ABB OFAF
- Brand
- ABB
- Series
- OFAF
- Rated current
- 2–800 A
- Supply voltage
- 500 – 250 V DC
- Ratings listed
- 25
