- Part number
- 1SCA022627R6190
- Model no
- OFAF2H355
- CE
- RoHS
ABB 1SCA022627R6190 OFAF2H355 355A 500VAC/250VDC 120kA HRC Fuse Link
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 250 | 1SCA022627R4650 | In stock | $9.99 | |
| 300 | 1SCA022627R5970 | In stock | $12.40 | |
| 355 | 1SCA022627R6190This part | In stock | $12.40 | |
| 400 | 1SCA022627R6270 | In stock | $12.40 | |
| 425 | 1SCA022627R6860 | Low stock | $26.17 |
Description
About the OFAF2H355
About the OFAF2H355
The ABB OFAF2H355 HRC fuse link (SKU: 1SCA022627R6190) is a high-rupturing-capacity fuse designed for reliable overcurrent and short-circuit protection in industrial power distribution systems. Rated at 355A and 500VAC / 250VDC with an impressive breaking capacity of 120 kA AC and 80 kA DC, the OFAF2H355 is engineered for demanding applications where fault currents are high and system integrity is critical.
Certifications & Standards
- RoHS: Compliant with the Restriction of Hazardous Substances Directive
- REACH: Compliant with EU REACH chemical safety regulations
- EU Directive 2011/65/EU & Amendment 2015/863: Compliant with EU restrictions on hazardous substances in electrical equipment
- IEC 60269: Designed and tested in accordance with the international standard for low-voltage fuses
- CE: CE marked, meeting applicable EU product safety and performance directives
- WEEE: Registered under the Waste Electrical and Electronic Equipment Directive for responsible end-of-life disposal
Applications & Use Cases
- Industrial power distribution panels and switchgear assemblies
- Motor feeder and branch circuit protection in manufacturing facilities
- Protection of transformers and busbars in commercial and industrial installations
- Control panel short-circuit protection in automation and process control systems
- DC power systems and battery-backed installations rated up to 250 VDC
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 4
| Product Net Width | 51 mm |
|---|---|
| Product Net Height | 150 mm |
| Product Net Depth / Length | 72 mm |
| Product Net Weight | 0.63 kg |
Technical 8
| Fuse Size | NH2 |
|---|---|
| Fuse System | DIN |
| Fuse Type | gG |
| Power Loss | at Rated Current 31.5 W, Total 31.5 W |
| Rated Current (In) | 355 A |
| Rated Voltage (Ur) | 500 V |
| Standards | IEC 60269 |
| Utilization Category | gL/gG (Cable protection/equipment protection) |
Show all 39 specifications ↓ Show less ↑26 more values in Identification, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA022627R6190 |
|---|---|
| Type designation | OFAF2H355 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019206035 |
| ETIM class | EC000055 |
| eCl@ss | 27142005 |
| Minimum Order Quantity | 3 piece |
| Customs Tariff Number | 85361090 |
| Country of Origin | Hungary |
External Classifications and Standards 4
| ETIM 10 | EC000055 - Knife blade fuse |
|---|---|
| UNSPSC | 39121600 |
| eClass | V11.1 : 27142005 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Logistics 10
| Package Level 1 Units | box 3 piece |
|---|---|
| Package Level 1 Width | 51 mm |
| Package Level 1 Depth / Length | 150 mm |
| Package Level 1 Height | 72 mm |
| Package Level 1 Gross Weight | 1.9845 kg |
| Package Level 1 EAN | 6417019206035 |
| Shipping weight | 1.984 kg |
| Ships from | Türkiye |
| Dispatch | 17 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SCA022627R6190
No documents are on file for this part yet.
Ask us for the datasheet
Other ratings
All 25 ratings in OFAF
| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 2 A | 1SCA022627R0230 | OFAF000H2 | In stock | $16.91 | |||
| 4 A | 1SCA022627R0310 | OFAF000H4 | In stock | $10.32 | |||
| 6 A | 1SCA022627R0400 | OFAF000H6 | In stock | $10.32 | |||
| 10 A | 1SCA022627R0580 | OFAF000H10 | In stock | $10.32 | |||
| 16 A | 1SCA022627R0660 | OFAF000H16 | In stock | $10.32 | |||
| 20 A | 1SCA022627R0740 | OFAF000H20 | In stock | $10.32 | |||
| 25 A | 1SCA022627R0820 | OFAF000H25 | Low stock | $10.32 | |||
| 32 A | 1SCA022627R0910 | OFAF000H32 | In stock | $10.32 | |||
| 35 A | 1SCA022627R1040 | OFAF000H35 | In stock | $10.32 | |||
| 40 A | 1SCA022627R1120 | OFAF000H40 | In stock | $10.32 | |||
| 50 A | 1SCA022627R1210 | OFAF000H50 | In stock | $10.32 | |||
| 63 A | 1SCA022627R1390 | OFAF000H63 | In stock | $10.32 | |||
| 80 A | 1SCA022627R1470 | OFAF000H80 | In stock | $10.32 | |||
| 100 A | 1SCA022627R1550 | OFAF000H100 | In stock | $10.32 | |||
| 125 A | 1SCA022627R1630 | OFAF00H125 | In stock | $14.11 | |||
| 160 A | 1SCA022627R1710 | OFAF00H160 | In stock | $14.11 | |||
| 200 A | 1SCA022627R4490 | OFAF1H200 | In stock | $9.99 | |||
| 224 A | 1SCA022627R4570 | OFAF1H224 | Critical stock | $9.99 | |||
| 250 A | 1SCA022627R4650 | OFAF1H250 | In stock | $9.99 | |||
| 300 A | 1SCA022627R5970 | OFAF2H300 | In stock | $12.40 | |||
| 355 A | 1SCA022627R6190 This part | OFAF2H355 | In stock | $12.40 | |||
| 400 A | 1SCA022627R6270 | OFAF2H400 | In stock | $12.40 | |||
| 425 A | 1SCA022627R6860 | OFAF3H425 | Low stock | $26.17 | |||
| 630 A | 1SCA022627R7160 | OFAF3H630 | Low stock | $26.17 | |||
| 800 A | 1SCA022627R7240 | OFAF3H800 | In stock | $54.76 |
Certifications
Certifications and standards
- CE
- RoHS
- IEC 60269
Quick answers
Questions about the OFAF2H355
What is the rated current of OFAF2H355?
The rated current of OFAF2H355 is 355 A.
Which supply voltage is OFAF2H355 rated for?
The rated operational voltage of OFAF2H355 is 500 – 250 V DC.
What is the HS code of OFAF2H355 for customs?
The tariff (HS) code on file for OFAF2H355 is 85361090.
What is the EAN of OFAF2H355?
The EAN (GTIN) of OFAF2H355 is 6417019206035.
Where does OFAF2H355 ship from, and how fast?
OFAF2H355 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
Reviews
Customer reviews
Series
ABB OFAF
- Brand
- ABB
- Series
- OFAF
- Rated current
- 2–800 A
- Supply voltage
- 500 – 250 V DC
- Ratings listed
- 25
