- Part number
- 1SCA022627R6270
- Model no
- OFAF2H400
- CE
- RoHS
ABB 1SCA022627R6270 OFAF2H400 400A 500VAC/250VDC 120kA HRC Fuse Link
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 300 | 1SCA022627R5970 | In stock | $12.40 | |
| 355 | 1SCA022627R6190 | In stock | $12.40 | |
| 400 | 1SCA022627R6270This part | In stock | $12.40 | |
| 425 | 1SCA022627R6860 | Low stock | $26.17 | |
| 630 | 1SCA022627R7160 | Low stock | $26.17 |
Description
About the OFAF2H400
About the OFAF2H400
The ABB OFAF2H400 HRC fuse link (SKU: 1SCA022627R6270) is a high-rupturing-capacity fuse designed for reliable overcurrent and short-circuit protection in industrial power distribution systems. Rated at 400A and 500VAC / 250VDC with a breaking capacity of 120 kA AC and 80 kA DC, the OFAF2H400 delivers robust fault interruption performance for demanding applications. Part of ABB's trusted OFAF series, it is fully compliant with IEC 60269 standards.
Certifications & Standards
- IEC 60269: Compliant with the international standard for low-voltage fuses, ensuring verified performance and safety ratings
- CE: Conforms to all applicable European Union directives for electrical equipment
- RoHS: Compliant with EU Directive 2011/65/EU on the restriction of hazardous substances in electrical and electronic equipment
- REACH: Meets EU REACH regulation requirements for chemical safety in industrial products
- EU Directive 2011/65/EU: Restriction of Hazardous Substances — fully compliant
- Amendment 2015/863: Updated RoHS compliance including restricted substances per the 2015 amendment
- WEEE: Registered under the Waste Electrical and Electronic Equipment directive for responsible end-of-life disposal
Applications & Use Cases
- Short-circuit and overcurrent protection in industrial switchboards and distribution panels
- Protection of busbars, cables, and transformers in manufacturing facilities
- Integration into fusegear assemblies and motor control centres (MCCs)
- Power distribution in process automation and heavy industrial environments
- DC circuit protection in energy storage and renewable energy systems (up to 250 VDC)
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 4
| Product Net Width | 51 mm |
|---|---|
| Product Net Height | 150 mm |
| Product Net Depth / Length | 72 mm |
| Product Net Weight | 0.63 kg |
Technical 8
| Fuse Size | NH2 |
|---|---|
| Fuse System | DIN |
| Fuse Type | gG |
| Power Loss | at Rated Current 32 W, Total 32 W |
| Rated Current (In) | 400 A |
| Rated Voltage (Ur) | 500 V |
| Standards | IEC 60269 |
| Utilization Category | gL/gG (Cable protection/equipment protection) |
Show all 39 specifications ↓ Show less ↑26 more values in Identification, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA022627R6270 |
|---|---|
| Type designation | OFAF2H400 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019206059 |
| ETIM class | EC000055 |
| eCl@ss | 27142005 |
| Minimum Order Quantity | 3 piece |
| Customs Tariff Number | 85361090 |
| Country of Origin | Hungary |
External Classifications and Standards 4
| ETIM 10 | EC000055 - Knife blade fuse |
|---|---|
| UNSPSC | 39121600 |
| eClass | V11.1 : 27142005 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Logistics 10
| Package Level 1 Units | box 3 piece |
|---|---|
| Package Level 1 Width | 51 mm |
| Package Level 1 Depth / Length | 150 mm |
| Package Level 1 Height | 72 mm |
| Package Level 1 Gross Weight | 1.9845 kg |
| Package Level 1 EAN | 6417019206059 |
| Shipping weight | 1.984 kg |
| Ships from | Türkiye |
| Dispatch | 17 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SCA022627R6270
No documents are on file for this part yet.
Ask us for the datasheet
Other ratings
All 25 ratings in OFAF
| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 2 A | 1SCA022627R0230 | OFAF000H2 | In stock | $16.91 | |||
| 4 A | 1SCA022627R0310 | OFAF000H4 | In stock | $10.32 | |||
| 6 A | 1SCA022627R0400 | OFAF000H6 | In stock | $10.32 | |||
| 10 A | 1SCA022627R0580 | OFAF000H10 | In stock | $10.32 | |||
| 16 A | 1SCA022627R0660 | OFAF000H16 | In stock | $10.32 | |||
| 20 A | 1SCA022627R0740 | OFAF000H20 | In stock | $10.32 | |||
| 25 A | 1SCA022627R0820 | OFAF000H25 | Low stock | $10.32 | |||
| 32 A | 1SCA022627R0910 | OFAF000H32 | In stock | $10.32 | |||
| 35 A | 1SCA022627R1040 | OFAF000H35 | In stock | $10.32 | |||
| 40 A | 1SCA022627R1120 | OFAF000H40 | In stock | $10.32 | |||
| 50 A | 1SCA022627R1210 | OFAF000H50 | In stock | $10.32 | |||
| 63 A | 1SCA022627R1390 | OFAF000H63 | In stock | $10.32 | |||
| 80 A | 1SCA022627R1470 | OFAF000H80 | In stock | $10.32 | |||
| 100 A | 1SCA022627R1550 | OFAF000H100 | In stock | $10.32 | |||
| 125 A | 1SCA022627R1630 | OFAF00H125 | In stock | $14.11 | |||
| 160 A | 1SCA022627R1710 | OFAF00H160 | In stock | $14.11 | |||
| 200 A | 1SCA022627R4490 | OFAF1H200 | In stock | $9.99 | |||
| 224 A | 1SCA022627R4570 | OFAF1H224 | Critical stock | $9.99 | |||
| 250 A | 1SCA022627R4650 | OFAF1H250 | In stock | $9.99 | |||
| 300 A | 1SCA022627R5970 | OFAF2H300 | In stock | $12.40 | |||
| 355 A | 1SCA022627R6190 | OFAF2H355 | In stock | $12.40 | |||
| 400 A | 1SCA022627R6270 This part | OFAF2H400 | In stock | $12.40 | |||
| 425 A | 1SCA022627R6860 | OFAF3H425 | Low stock | $26.17 | |||
| 630 A | 1SCA022627R7160 | OFAF3H630 | Low stock | $26.17 | |||
| 800 A | 1SCA022627R7240 | OFAF3H800 | In stock | $54.76 |
Certifications
Certifications and standards
- CE
- RoHS
- IEC 60269
Quick answers
Questions about the OFAF2H400
What is the rated current of OFAF2H400?
The rated current of OFAF2H400 is 400 A.
Which supply voltage is OFAF2H400 rated for?
The rated operational voltage of OFAF2H400 is 500 – 250 V DC.
What is the HS code of OFAF2H400 for customs?
The tariff (HS) code on file for OFAF2H400 is 85361090.
What is the EAN of OFAF2H400?
The EAN (GTIN) of OFAF2H400 is 6417019206059.
Where does OFAF2H400 ship from, and how fast?
OFAF2H400 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
Reviews
Customer reviews
Series
ABB OFAF
- Brand
- ABB
- Series
- OFAF
- Rated current
- 2–800 A
- Supply voltage
- 500 – 250 V DC
- Ratings listed
- 25
