- Part number
- 1SCA022627R4650
- Model no
- OFAF1H250
- CE
- RoHS
ABB 1SCA022627R4650 OFAF1H250 250A 500VAC/250VDC 120kA HRC Fuse Link
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 200 | 1SCA022627R4490 | In stock | $9.99 | |
| 224 | 1SCA022627R4570 | Critical stock | $9.99 | |
| 250 | 1SCA022627R4650This part | In stock | $9.99 | |
| 300 | 1SCA022627R5970 | In stock | $12.40 | |
| 355 | 1SCA022627R6190 | In stock | $12.40 |
Description
About the OFAF1H250
About the OFAF1H250
The ABB OFAF1H250 HRC fuse link (SKU: 1SCA022627R4650) is a high-rupturing-capacity fuse designed for reliable overcurrent and short-circuit protection in industrial power distribution systems. Rated at 250A and 500VAC / 250VDC with a breaking capacity of 120 kA AC and 80 kA DC, the OFAF1H250 delivers robust protection for demanding industrial applications including motor branch circuits, distribution panels, and control cabinets.
Certifications & Standards
- IEC 60269: Compliant with international standard for low-voltage fuses
- CE: Meets European Conformity requirements for electrical equipment
- RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances
- REACH: Compliant with EU REACH regulation on chemical safety
- EU Directive 2011/65/EU & Amendment 2015/863: Full compliance with RoHS recast and updated substance restrictions
- WEEE: Registered under the Waste Electrical and Electronic Equipment directive for responsible end-of-life handling
Applications & Use Cases
- Motor branch circuit protection in industrial automation and control panels
- Distribution board and busbar protection in commercial and industrial facilities
- Short-circuit protection for cables, transformers, and switchgear up to 500VAC
- DC circuit protection in renewable energy and battery storage systems up to 250VDC
- Replacement fuse link for ABB OFAF-series fuse holders and bases
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 4
| Product Net Width | 40 mm |
|---|---|
| Product Net Height | 135 mm |
| Product Net Depth / Length | 65 mm |
| Product Net Weight | 0.4 kg |
Technical 8
| Fuse Size | NH1 |
|---|---|
| Fuse System | DIN |
| Fuse Type | gG |
| Power Loss | at Rated Current 20 W, Total 20 W |
| Rated Current (In) | 250 A |
| Rated Voltage (Ur) | 500 V |
| Standards | IEC 60269 |
| Utilization Category | gL/gG (Cable protection/equipment protection) |
Show all 40 specifications ↓ Show less ↑27 more values in Identification, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA022627R4650 |
|---|---|
| Type designation | OFAF1H250 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019205861 |
| ETIM class | EC000055 |
| eCl@ss | 27142005 |
| Minimum Order Quantity | 3 piece |
| Customs Tariff Number | 85361090 |
| Country of Origin | Hungary |
External Classifications and Standards 5
| ETIM 10 | EC000055 - Knife blade fuse |
|---|---|
| UNSPSC | 39121600 |
| eClass | V11.1 : 27142005 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| E-Number (Sweden) | 2040130 |
Logistics 10
| Package Level 1 Units | box 3 piece |
|---|---|
| Package Level 1 Width | 40 mm |
| Package Level 1 Depth / Length | 135 mm |
| Package Level 1 Height | 65 mm |
| Package Level 1 Gross Weight | 1.26 kg |
| Package Level 1 EAN | 6417019205861 |
| Shipping weight | 1.26 kg |
| Ships from | Türkiye |
| Dispatch | 17 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SCA022627R4650
No documents are on file for this part yet.
Ask us for the datasheet
Other ratings
All 25 ratings in OFAF
| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 2 A | 1SCA022627R0230 | OFAF000H2 | In stock | $16.91 | |||
| 4 A | 1SCA022627R0310 | OFAF000H4 | In stock | $10.32 | |||
| 6 A | 1SCA022627R0400 | OFAF000H6 | In stock | $10.32 | |||
| 10 A | 1SCA022627R0580 | OFAF000H10 | In stock | $10.32 | |||
| 16 A | 1SCA022627R0660 | OFAF000H16 | In stock | $10.32 | |||
| 20 A | 1SCA022627R0740 | OFAF000H20 | In stock | $10.32 | |||
| 25 A | 1SCA022627R0820 | OFAF000H25 | Low stock | $10.32 | |||
| 32 A | 1SCA022627R0910 | OFAF000H32 | In stock | $10.32 | |||
| 35 A | 1SCA022627R1040 | OFAF000H35 | In stock | $10.32 | |||
| 40 A | 1SCA022627R1120 | OFAF000H40 | In stock | $10.32 | |||
| 50 A | 1SCA022627R1210 | OFAF000H50 | In stock | $10.32 | |||
| 63 A | 1SCA022627R1390 | OFAF000H63 | In stock | $10.32 | |||
| 80 A | 1SCA022627R1470 | OFAF000H80 | In stock | $10.32 | |||
| 100 A | 1SCA022627R1550 | OFAF000H100 | In stock | $10.32 | |||
| 125 A | 1SCA022627R1630 | OFAF00H125 | In stock | $14.11 | |||
| 160 A | 1SCA022627R1710 | OFAF00H160 | In stock | $14.11 | |||
| 200 A | 1SCA022627R4490 | OFAF1H200 | In stock | $9.99 | |||
| 224 A | 1SCA022627R4570 | OFAF1H224 | Critical stock | $9.99 | |||
| 250 A | 1SCA022627R4650 This part | OFAF1H250 | In stock | $9.99 | |||
| 300 A | 1SCA022627R5970 | OFAF2H300 | In stock | $12.40 | |||
| 355 A | 1SCA022627R6190 | OFAF2H355 | In stock | $12.40 | |||
| 400 A | 1SCA022627R6270 | OFAF2H400 | In stock | $12.40 | |||
| 425 A | 1SCA022627R6860 | OFAF3H425 | Low stock | $26.17 | |||
| 630 A | 1SCA022627R7160 | OFAF3H630 | Low stock | $26.17 | |||
| 800 A | 1SCA022627R7240 | OFAF3H800 | In stock | $54.76 |
Certifications
Certifications and standards
- CE
- RoHS
- IEC 60269
Quick answers
Questions about the OFAF1H250
What is the rated current of OFAF1H250?
The rated current of OFAF1H250 is 250 A.
Which supply voltage is OFAF1H250 rated for?
The rated operational voltage of OFAF1H250 is 500 – 250 V DC.
What is the HS code of OFAF1H250 for customs?
The tariff (HS) code on file for OFAF1H250 is 85361090.
What is the EAN of OFAF1H250?
The EAN (GTIN) of OFAF1H250 is 6417019205861.
Where does OFAF1H250 ship from, and how fast?
OFAF1H250 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
Reviews
Customer reviews
Series
ABB OFAF
- Brand
- ABB
- Series
- OFAF
- Rated current
- 2–800 A
- Supply voltage
- 500 – 250 V DC
- Ratings listed
- 25
