- Part number
- 1SCA022627R4490
- Model no
- OFAF1H200
- CE
- RoHS
ABB 1SCA022627R4490 OFAF1H200 200A 500VAC/250VDC 120kA HRC Fuse Link
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 125 | 1SCA022627R1630 | In stock | $14.11 | |
| 160 | 1SCA022627R1710 | In stock | $14.11 | |
| 200 | 1SCA022627R4490This part | In stock | $9.99 | |
| 224 | 1SCA022627R4570 | Critical stock | $9.99 | |
| 250 | 1SCA022627R4650 | In stock | $9.99 |
Description
About the OFAF1H200
About the OFAF1H200
The ABB OFAF1H200 HRC fuse link (SKU: 1SCA022627R4490) is a high-rupturing-capacity fuse rated at 200A and 500VAC / 250VDC, delivering a breaking capacity of 120 kA AC and 80 kA DC for robust short-circuit protection in industrial power distribution systems. Part of ABB's trusted OFAF series, the OFAF1H200 is engineered to provide reliable overcurrent and short-circuit protection in control panels, switchboards, and motor circuits where demanding fault currents must be safely interrupted.
Certifications & Standards
- IEC 60269: International standard for low-voltage fuses — design, performance, and testing requirements
- CE: Conformity with European health, safety, and environmental protection requirements
- RoHS: Compliant with EU Directive 2011/65/EU — restriction of hazardous substances in electrical equipment
- REACH: Compliant with EU regulation on the registration, evaluation, authorisation and restriction of chemicals
- EU Directive 2011/65/EU: RoHS 2 directive restricting use of hazardous substances
- EU Directive 2015/863: RoHS 3 amendment extending the list of restricted substances
- WEEE: Compliant with Waste Electrical and Electronic Equipment Directive for responsible end-of-life disposal
Applications & Use Cases
- Short-circuit and overcurrent protection in industrial switchboards and distribution panels
- Motor circuit protection in manufacturing and process automation environments
- Fusegear assemblies in commercial and industrial buildings requiring IEC 60269-compliant protection
- DC bus protection in renewable energy, battery systems, and drive applications up to 250 VDC
- Control panel protection where high breaking capacity up to 120 kA AC is required
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 4
| Product Net Width | 40 mm |
|---|---|
| Product Net Height | 135 mm |
| Product Net Depth / Length | 65 mm |
| Product Net Weight | 0.4 kg |
Technical 8
| Fuse Size | NH1 |
|---|---|
| Fuse System | DIN |
| Fuse Type | gG |
| Power Loss | at Rated Current 18 W, Total 18 W |
| Rated Current (In) | 200 A |
| Rated Voltage (Ur) | 500 V |
| Standards | IEC 60269 |
| Utilization Category | gL/gG (Cable protection/equipment protection) |
Show all 40 specifications ↓ Show less ↑27 more values in Identification, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA022627R4490 |
|---|---|
| Type designation | OFAF1H200 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019205830 |
| ETIM class | EC000055 |
| eCl@ss | 27142005 |
| Minimum Order Quantity | 3 piece |
| Customs Tariff Number | 85361090 |
| Country of Origin | Hungary |
External Classifications and Standards 5
| ETIM 10 | EC000055 - Knife blade fuse |
|---|---|
| UNSPSC | 39121600 |
| eClass | V11.1 : 27142005 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| E-Number (Sweden) | 2040126 |
Logistics 10
| Package Level 1 Units | box 3 piece |
|---|---|
| Package Level 1 Width | 40 mm |
| Package Level 1 Depth / Length | 135 mm |
| Package Level 1 Height | 65 mm |
| Package Level 1 Gross Weight | 1.26 kg |
| Package Level 1 EAN | 6417019205830 |
| Shipping weight | 1.26 kg |
| Ships from | Türkiye |
| Dispatch | 17 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SCA022627R4490
No documents are on file for this part yet.
Ask us for the datasheet
Other ratings
All 25 ratings in OFAF
| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 2 A | 1SCA022627R0230 | OFAF000H2 | In stock | $16.91 | |||
| 4 A | 1SCA022627R0310 | OFAF000H4 | In stock | $10.32 | |||
| 6 A | 1SCA022627R0400 | OFAF000H6 | In stock | $10.32 | |||
| 10 A | 1SCA022627R0580 | OFAF000H10 | In stock | $10.32 | |||
| 16 A | 1SCA022627R0660 | OFAF000H16 | In stock | $10.32 | |||
| 20 A | 1SCA022627R0740 | OFAF000H20 | In stock | $10.32 | |||
| 25 A | 1SCA022627R0820 | OFAF000H25 | Low stock | $10.32 | |||
| 32 A | 1SCA022627R0910 | OFAF000H32 | In stock | $10.32 | |||
| 35 A | 1SCA022627R1040 | OFAF000H35 | In stock | $10.32 | |||
| 40 A | 1SCA022627R1120 | OFAF000H40 | In stock | $10.32 | |||
| 50 A | 1SCA022627R1210 | OFAF000H50 | In stock | $10.32 | |||
| 63 A | 1SCA022627R1390 | OFAF000H63 | In stock | $10.32 | |||
| 80 A | 1SCA022627R1470 | OFAF000H80 | In stock | $10.32 | |||
| 100 A | 1SCA022627R1550 | OFAF000H100 | In stock | $10.32 | |||
| 125 A | 1SCA022627R1630 | OFAF00H125 | In stock | $14.11 | |||
| 160 A | 1SCA022627R1710 | OFAF00H160 | In stock | $14.11 | |||
| 200 A | 1SCA022627R4490 This part | OFAF1H200 | In stock | $9.99 | |||
| 224 A | 1SCA022627R4570 | OFAF1H224 | Critical stock | $9.99 | |||
| 250 A | 1SCA022627R4650 | OFAF1H250 | In stock | $9.99 | |||
| 300 A | 1SCA022627R5970 | OFAF2H300 | In stock | $12.40 | |||
| 355 A | 1SCA022627R6190 | OFAF2H355 | In stock | $12.40 | |||
| 400 A | 1SCA022627R6270 | OFAF2H400 | In stock | $12.40 | |||
| 425 A | 1SCA022627R6860 | OFAF3H425 | Low stock | $26.17 | |||
| 630 A | 1SCA022627R7160 | OFAF3H630 | Low stock | $26.17 | |||
| 800 A | 1SCA022627R7240 | OFAF3H800 | In stock | $54.76 |
Certifications
Certifications and standards
- CE
- RoHS
- IEC 60269
Quick answers
Questions about the OFAF1H200
What is the rated current of OFAF1H200?
The rated current of OFAF1H200 is 200 A.
Which supply voltage is OFAF1H200 rated for?
The rated operational voltage of OFAF1H200 is 500 – 250 V DC.
What is the HS code of OFAF1H200 for customs?
The tariff (HS) code on file for OFAF1H200 is 85361090.
What is the EAN of OFAF1H200?
The EAN (GTIN) of OFAF1H200 is 6417019205830.
Where does OFAF1H200 ship from, and how fast?
OFAF1H200 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
