ABB 1SBL137001R1101 AF09-30-01-11 3-Pole 9A 690V AC 24-60V Coil Power Contactor AC Switching

The ABB AF09-30-01-11 power contactor (SKU: 1SBL137001R1101) is a 3-pole AC switching contactor rated for 9A continuous current at up to 690V AC, delivering 4 kW motor switching capability. Featuring a wide-range coil accepting 24–60V AC (50/60Hz) and 20–60V DC, the AF09-30-01-11 is engineered for industrial control panels, machine automation, and motor starter assemblies where reliable, space-efficient switching is critical.

Technical Specifications

Certifications & Standards

• CE: Conformity with European Union safety, health, and environmental requirements
• UKCA: UK Conformity Assessed marking for Great Britain market
• UL: Underwriters Laboratories product safety certification
• UL 60947-4-1: UL standard for low-voltage switchgear — electromechanical contactors and motor starters
• UL 60335-2-40: UL standard for particular requirements for electrical heat pumps, air conditioners and dehumidifiers
• UL 60335-2-40 LZGH2 A2L: UL certification for A2L low-GWP refrigerant applications
• CSA: Canadian Standards Association product certification
• CSA C22.2 No. 60335-2-40: CSA standard for heat pumps, air conditioners and dehumidifiers
• CSA C22.2 No. 60335-2-40 LZGH2 A2L: CSA certification for A2L refrigerant applications
• CSA C22.2 No. 60947-4-1: CSA standard for contactors and motor starters
• CSA C22.2 No. 60335: CSA household and similar electrical appliances standard
• CSA C22.2 No. 60947: CSA low-voltage switchgear and controlgear standard
• CCC: China Compulsory Certification for the Chinese market
• CQC: China Quality Certification for voluntary product certification
• CB: IEC System of Conformity Assessment for Electrotechnical Equipment and Components
• ABS: American Bureau of Shipping marine product certification
• BV: Bureau Veritas marine and industrial product certification
• IEC 60947-1 / EN 60947-1 / IEC/EN 60947-1: General rules for low-voltage switchgear and controlgear
• IEC 60947-4 / EN 60947-4 / IEC/EN 60947-4 / IEC60947-4: Contactors and motor starters standard
• IEC 60947-5 / IEC60947-5: Control circuit devices and switching elements
• IEC 60068-227: Environmental testing — vibration test method
• EN 45555: General methods for the assessment of the ability of energy-related products to be repaired, reused and recycled
• EN 45555-92: Supplementary requirements for specific energy-related product categories
• REACH: EU regulation on Registration, Evaluation, Authorisation and Restriction of Chemicals
• RoHS: Restriction of Hazardous Substances Directive compliance
• WEEE: Waste Electrical and Electronic Equipment Directive compliance

Applications & Use Cases

• 3-phase motor switching and direct-on-line (DOL) motor starters in industrial machinery
• HVAC and refrigeration system control with A2L refrigerant compatibility (UL/CSA 60335-2-40)
• Control panel and MCC (Motor Control Centre) assemblies
• Pump, fan, and compressor control in building automation systems
• Marine and offshore applications (ABS, BV approved)
• Industrial automation and process control across global markets (CE, UKCA, CCC, UL, CSA)
