ABB 1SBL136001R2101 AF09Z-30-01-21 3P 9A 690V 24-60V AC/DC Coil Power Contactor AC Switching

The ABB AF09Z-30-01-21 (SKU 1SBL136001R2101) is a 3-pole power contactor designed for AC switching applications, rated at 9A with a maximum operational voltage of 690V AC. Part of ABB's AF series, the AF09Z-30-01-21 features a wide-range coil accepting 24–60V AC (50/60Hz) and 20–60V DC, delivering reliable performance in compact control panel installations. With a rated motor power of 4kW and dimensions of only 45×86×77mm, this contactor combines versatility with a minimal footprint.

Technical Specifications

Certifications & Standards

• CE: Conforms to EU low-voltage and electromagnetic compatibility directives
• UKCA: UK Conformity Assessed marking for the Great Britain market
• IEC 60947-1 / EN 60947-1: General rules for low-voltage switchgear and controlgear
• IEC 60947-4 / EN 60947-4: Contactors and motor-starters standard
• UL 60947-4-1: UL-listed to the North American contactor and motor-starter standard
• UL 60335-2-40 (LZGH2A2L): UL certification for particular requirements — heat pumps, air conditioners and dehumidifiers
• CSA C22.2 No. 60335-2-40 (LZGH2A2L): Canadian Standards Association certification for heat pump and HVAC applications
• CSA C22.2 No. 60947-4-1: CSA certification for contactors and motor-starters
• CB: IEC System of Conformity Assessment for Electrotechnical Equipment and Components
• CCC: China Compulsory Certification
• CQC: China Quality Certification Centre voluntary certification
• ABS: American Bureau of Shipping type approval for marine applications
• BV: Bureau Veritas type approval for marine and offshore applications
• IEC 60068-2-27: Environmental testing — shock
• EN 45555: General methods for assessing the energy efficiency and resource efficiency of networked standby loss
• EN 45555-92: Supplementary standard for energy-related products
• REACH: Compliant with EU REACH regulation on chemical substances
• RoHS: Restriction of Hazardous Substances compliant
• WEEE: Waste Electrical and Electronic Equipment directive compliant

Applications & Use Cases

The ABB AF09Z-30-01-21 power contactor is well-suited for motor control, HVAC equipment switching, industrial automation control panels, pump and fan circuits, and building management systems. Its wide-range coil (24–60V AC/DC) simplifies global deployments by accepting varying control supply voltages without additional components. The compact 45mm width makes it ideal for space-constrained DIN rail assemblies, while multi-standard certifications including ABS and BV cover marine and offshore installations.
