ABB 1SBL136001R2110 AF09Z-30-10-21 3-Pole 9A 24-60V AC/DC Coil AF Series Power Contactor AC Switching

The ABB AF09Z-30-10-21 power contactor (SKU: 1SBL136001R2110) is a 3-pole AC switching contactor rated at 9A and up to 690V, designed for reliable motor and load switching in industrial control panels. Part of ABB's AF series, this compact contactor features a wide-range coil accepting 24–60V AC (50/60Hz) and 20–60V DC, making it highly versatile for mixed-voltage control systems. With a 4kW motor rating and compact 45×86×77mm footprint weighing just 0.31kg, it suits space-constrained installations.

Technical Specifications

Certifications & Standards

• CE: European Conformity — meets EU safety and regulatory requirements
• UKCA: UK Conformity Assessed — compliant for Great Britain market
• UL: Underwriters Laboratories — certified for North American safety
• UL 60947-4-1: UL standard for electromechanical contactors and motor starters
• UL 60335-2-40: UL safety standard for heat pumps, air conditioners and dehumidifiers (ref: LZGH2A2L)
• CSA: Canadian Standards Association — certified for Canadian market
• CSA C22.2 No. 60947-4-1: CSA standard for electromechanical contactors and motor starters
• CSA C22.2 No. 60335-2-40: CSA safety standard for air conditioning and heat pump equipment (ref: LZGH2A2L)
• IEC 60947-1 / EN 60947-1: General rules for low-voltage switchgear and controlgear
• IEC 60947-4 / EN 60947-4: Contactors and motor starters standard
• IEC/EN 60947-1: Combined IEC/EN low-voltage switchgear general requirements
• IEC/EN 60947-4: Combined IEC/EN contactors and motor-starters standard
• IEC 60715: Dimensions of low-voltage switchgear — DIN rail mounting
• IEC 60068-2: Environmental testing standard for electrical components
• CB: IECEE CB Scheme — international certification for electrotechnical products
• CCC: China Compulsory Certification — approved for Chinese market
• CQC: China Quality Certification — voluntary quality certification for China
• ABS: American Bureau of Shipping — marine and offshore approval
• BV: Bureau Veritas — marine and industrial certification
• EN 45555: General methods for the assessment of the ability to recover resources from electrical equipment
• EN 45555-92: Supplementary EN 45555 resource recovery assessment
• REACH: EU chemical safety regulation compliance
• RoHS: Restriction of Hazardous Substances — EU compliant
• WEEE: Waste Electrical and Electronic Equipment directive compliant
