ABB 1SAE351111R0640 ESB63-40N-06 63A 4NO 230V 4-Pole Installation Contactor for Distribution Board
$85.15
- Description
The ABB ESB63-40N-06 installation contactor (SKU: 1SAE351111R0640) is a 63 A, 4-pole (4NO) device rated for 230 V control circuit operation at up to 400 Hz, purpose-built for switching loads in residential and commercial distribution boards. Part of ABB's ESB63-N series, the ESB63-40N-06 delivers reliable, compact switching in a 54 × 65 × 85 mm (W × D × H) enclosure weighing just 0.405 kg, making it ideal for DIN-rail installation in tight panel layouts.
Technical Specifications
| Catalog Number | ESB63-40N-06 |
| SKU | 1SAE351111R0640 |
| Brand | ABB |
| Series | ESB63-N |
| Rated Current | 63 A |
| Control Voltage | 230 V |
| Control Circuit Frequency | 400 Hz |
| Number of Poles | 4 |
| Contact Configuration | 4NO + 0NC |
| Product Type | Installation Contactor |
| Dimensions (W × D × H) | 54 × 65 × 85 mm |
| Weight | 0.405 kg |
| EAN | 4013614519239 |
Certifications & Standards
- CE: Conformité Européenne — meets EU safety, health, and environmental protection requirements
- UKCA: UK Conformity Assessed — approved for the Great Britain market post-Brexit
- UL: Underwriters Laboratories certified (UL 240, UL 480) for North American markets
- CSA: Canadian Standards Association approval for Canadian market
- NF: French national standards certification
- RINA: Italian naval classification society type approval
- IEC/EN 60947-1: General rules for low-voltage switchgear and controlgear
- IEC/EN 60947-4: Contactors and motor-starters — electromechanical contactors and motor-starters
- IEC/EN 61095: Electromechanical contactors for household and similar purposes
- IEC 60335-2: Safety of household and similar electrical appliances
- IEC 60068-2: Environmental testing — climatic and mechanical durability
- CCC: China Compulsory Certification for the Chinese market
- REACH: Compliant with EU regulation on registration, evaluation, authorisation and restriction of chemicals
- RoHS: Restriction of Hazardous Substances — free from restricted materials
- WEEE: Waste Electrical and Electronic Equipment directive compliance
- EN45555: General methods for the assessment of the ability of energy-related products to be repaired, reused, and recycled
Applications & Use Cases
The ABB ESB63-40N-06 installation contactor is designed for distribution board applications where reliable, remotely controlled switching of lighting, heating, HVAC, and general electrical loads is required. Its 4NO contact configuration makes it well suited to centrally controlled lighting circuits, time-controlled heating systems, and tariff switching in residential, commercial, and light industrial installations. The 400 Hz control circuit compatibility also makes the ESB63-40N-06 suitable for special-purpose control systems and marine or aerospace auxiliary panel applications.
