Part number
XVGB3T
$73.37 On request Dispatch — · From TürkiyeGet a Quote
Harmony XVG

Schneider Electric XVGB3T Harmony XVG 60 mm Red Amber Green Steady 24 V AC/DC Direct Mount Signal Tower

Schneider Electric XVGB3T - Harmony XVG 3-colour steady tower light, 60 mm, 24 V AC/DC, IP23.

Rated operational voltage
24–DC V DC
Description

About the XVGB3T

The Schneider Electric XVGB3T is a complete pre-wired monolithic tower light from the Harmony XVG range, combining 3 steady LED colour segments (red/amber/green) on a 60 mm diameter body. It runs on 24 V AC/DC, mounts by direct tube mounting, and reaches IP23 ingress protection for direct installation on the machine.

Certifications & Standards

  • CE
  • EAC

Selection Notes

XVGB3T uses direct tube mounting rather than the bracket-mounted versions, which sets its IP23 ingress rating and 0.39 kg weight. With no buzzer in the base, it stays a purely visual indicator for areas where audible alarms are not wanted or already covered by another device. Pick this mounting style when the panel or machine frame already matches its fixing pattern; swapping between the L-bracket, fixing-plate, foldable-bracket, direct-tube and base-mount variants mainly changes how the tube is anchored, not the light logic itself.

Specification

Full specification

51 values · Last verified 30 Oct 2026

Main 10

Range of product Harmony XVG
Product or component type Complete pre-wired monolithic tower light
Beacon or indicator bank unit type 3 illuminated units
Material PC (UL94 V-2): globe, ABS (UL94HB): tube body, Aluminium: tube
Mounting diameter 60 mm
Component name XVG
Device mounting Direct tube mounting
Light source LED steady red, LED steady green, LED steady amber
Light block color Red/orange/green
Indicator bank base type Base without buzzer

Complementary 8

[Us] rated supply voltage 24 V AC/DC
Cable cross section 0.33 mm²
Discrete output type PNP and NPN
[Uimp] rated impulse withstand voltage 0.5 kV
Current consumption 109 mA
Power consumption in W 3.1 W
Fundamental frequency 2.64 kHz
Net weight 0.39 kg

Environment 4

Product certifications CE, EAC
Ambient air temperature for storage -35…70 °C
Ambient air temperature for operation -10…50 °C
IP degree of protection IP23
Show all 51 specifications ↓ Show less ↑29 more values in Identification, Contractual warranty, Logistics.

Identification 6

Part number XVGB3T
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 22

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 9.000 cm
Package 1 Width 14.000 cm
Package 1 Length 57.000 cm
Package 1 Weight 606.000 g
Unit Type of Package 2 S04
Number of Units in Package 2 8
Package 2 Height 30.000 cm
Package 2 Width 40.000 cm
Package 2 Length 60.000 cm
Package 2 Weight 5.525 kg
Unit Type of Package 3 P06
Number of Units in Package 3 24
Package 3 Height 75.000 cm
Package 3 Width 60.000 cm
Package 3 Length 80.000 cm
Package 3 Weight 25.075 kg
Shipping weight 0.39 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for XVGB3T

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • CE
  • EAC
Quick answers

Questions about the XVGB3T

Which supply voltage is XVGB3T rated for?

The rated operational voltage of XVGB3T is 24–DC V DC.

What is the HS code of XVGB3T for customs?

The tariff (HS) code on file for XVGB3T is 853180.

Where does XVGB3T ship from, and how fast?

XVGB3T ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
