- Part number
- XVGB2W
Description
About the XVGB2W
About the XVGB2W
The Schneider Electric XVGB2W is a complete pre-wired monolithic tower light from the Harmony XVG range, combining 2 steady LED colour segments (red/green) on a 60 mm diameter body. It runs on 24 V AC/DC, mounts by base mounting, and reaches IP53 ingress protection for direct installation on the machine.
Certifications & Standards
- CE
- EAC
Selection Notes
XVGB2W uses base mounting rather than the tube-mounted versions, which sets its IP53 ingress rating and 0.2 kg weight. With no buzzer in the base, it stays a purely visual indicator for areas where audible alarms are not wanted or already covered by another device. Pick this mounting style when the panel or machine frame already matches its fixing pattern; swapping between the L-bracket, fixing-plate, foldable-bracket, direct-tube and base-mount variants mainly changes how the tube is anchored, not the light logic itself.
Specification
Full specification
Main 10
| Range of product | Harmony XVG |
|---|---|
| Product or component type | Complete pre-wired monolithic tower light |
| Beacon or indicator bank unit type | 2 illuminated units |
| Material | PC (UL94 V-2): globe, ABS (UL94HB): tube body, Aluminium: tube |
| Mounting diameter | 60 mm |
| Component name | XVG |
| Device mounting | Base mounting |
| Light source | LED steady red, LED steady green |
| Light block color | Red/green |
| Indicator bank base type | Base without buzzer |
Complementary 8
| [Us] rated supply voltage | 24 V AC/DC |
|---|---|
| Cable cross section | 0.33 mm² |
| Discrete output type | PNP and NPN |
| [Uimp] rated impulse withstand voltage | 0.5 kV |
| Current consumption | 68 mA |
| Power consumption in W | 1.6 W |
| Fundamental frequency | 2.64 kHz |
| Net weight | 0.2 kg |
Environment 4
| Product certifications | CE, EAC |
|---|---|
| Ambient air temperature for storage | -35…70 °C |
| Ambient air temperature for operation | -10…50 °C |
| IP degree of protection | IP53 |
Show all 51 specifications ↓ Show less ↑29 more values in Identification, Contractual warranty, Logistics.
Identification 6
| Part number | XVGB2W |
|---|---|
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 22
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 31.0 cm |
| Package 1 Width | 8.5 cm |
| Package 1 Length | 7.5 cm |
| Package 1 Weight | 307.0 g |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 21 |
| Package 2 Height | 30 cm |
| Package 2 Width | 40 cm |
| Package 2 Length | 60 cm |
| Package 2 Weight | 7.55 kg |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 84 |
| Package 3 Height | 75 cm |
| Package 3 Width | 60 cm |
| Package 3 Length | 80 cm |
| Package 3 Weight | 38 kg |
| Shipping weight | 0.2 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for XVGB2W
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- EAC
Quick answers
Questions about the XVGB2W
Which supply voltage is XVGB2W rated for?
The rated operational voltage of XVGB2W is 24–DC V DC.
What is the HS code of XVGB2W for customs?
The tariff (HS) code on file for XVGB2W is 853180.
Where does XVGB2W ship from, and how fast?
XVGB2W ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
