Part number
XVB7C31
Model no
XVB7
$170.78 On request Dispatch — · From TürkiyeGet a Quote
Harmony XVB7

Schneider Electric XVB7C31 Harmony XVB7 Base Module Ø70 mm IO Link 24 V DC Signal Tower

Schneider Electric XVB7C31 - Harmony XVB7 IO Link base module, Ø70 mm, 24 V DC, IP66.

Range of Product
Harmony XVB7
Product or Component Type
Base module
Device Composition
Base direct/tube & cover
Device short name
XVB7
Mounting diameter
2.8 in (70 mm)
Electrical Connection
IO Link
EAN
3606487129271
Description

About the XVB7

The Schneider Electric XVB7C31 is a IO Link base module for the Harmony XVB7 range of Ø 70 mm modular tower lights. It supplies power to up to 5 modules (4 lens + 1 sound or 5 lens) and connects via an A-coded M12 connector on a 15 cm cable, running on 24 V DC. The dark grey polycarbonate base reaches IP66 and weighs 0.227 kg.

Certifications & Standards

  • cULus
  • CCC
  • RCM
  • UKCA
  • CE
  • UL 60947-5-1
  • IEC 60947-5-1
  • CSA C22.2 No 60947-5-1

Selection Notes

XVB7C31 uses an A-coded M12 connector instead of screw or spring terminals, which trades a small amount of wiring flexibility for faster installation and replacement. Its IO-Link v1.1 interface lets the controller read module status over the same cable that supplies power, instead of wiring a separate discrete output. Pick the terminal-block base instead when the application already runs flying-lead cable to the tower light location.

Specification

Full specification

45 values · Last verified 30 Oct 2026

Main 13

Range of Product Harmony XVB7
Product or Component Type Base module
Device Composition Base direct/tube & cover
Device short name XVB7
Mounting diameter 2.8 in (70 mm)
Electrical Connection IO Link
Communication Port Protocol IO Link v1.1
Fixing Mode Direct or tube fixing
Mounting position Upright/inverted
Assembly style Up to 5 Modules (4 lens + 1 sound or 5 lens)
Material Polycarbonate
Housing Colour Dark grey
Net Weight 0.500 lb(US) (0.227 kg)

Complementary 9

[Ue] rated operational voltage 24 V DC
Rated operational voltage limits 21.6...26.4 V DC
Electrical shock protection class Class II
Current consumption 6 mA
Output current 500 mA max per channel, 1600 mA max all channels
Connections - terminals M12, 5 Pol Male, A-Coded port
Type of Cable M12 cable 15cm
[Ui] Rated Insulation Voltage 50 V
[Uimp] rated impulse withstand voltage 0.5 kV

Environment 9

Pollution degree 2
Ambient Air Temperature for Operation -13…140 °F (-25…60 °C)
Ambient Air Temperature for Storage -40…158 °F (-40…70 °C)
IP Degree of Protection IP66
Environmental Type ratings UL type 4X/13
Vibration resistance 6 gn +/- 0.5 mm 10…500 Hz)in operation
Shock resistance 30 gn 6 ms) in operation
Standards UL 60947-5-1, IEC 60947-5-1, CSA C22.2 No 60947-5-1
Product Certifications cULus, CCC, RCM, UKCA, CE
Show all 45 specifications ↓ Show less ↑14 more values in Identification, Contractual warranty, Logistics.

Identification 8

Part number XVB7C31
Type designation XVB7
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 3606487129271

Contractual warranty 1

Warranty (in months) 18

Logistics 5

Country of origin DE
Shipping weight 0.227 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for XVB7C31

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • cULus
  • CE
  • UKCA
  • CCC
  • UL 60947-5-1
  • IEC 60947-5-1
  • CSA C22.2 No 60947-5-1
Quick answers

Questions about the XVB7

What is the HS code of XVB7 for customs?

The tariff (HS) code on file for XVB7 is 853180.

What is the EAN of XVB7?

The EAN (GTIN) of XVB7 is 3606487129271.

Where does XVB7 ship from, and how fast?

XVB7 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
