Schneider Electric METSEPM5560 PowerLogic PM5560 Class 0.2S 63rd Harmonic 2 Ethernet 4DI 2DO Power Meter

The Schneider Electric METSEPM5560 is a PowerLogic PM5560 flush-mount power meter with Class 0.2S accuracy to IEC 62053-22 and 128 samples per cycle. It measures voltage, current, frequency, power factor and active/reactive power, resolves harmonics to the 63rd order, and monitors neutral current directly with calculated ground current. Dual Ethernet ports carry Modbus TCP/IP, EtherNet/IP, BACnet/IP and DNP3, alongside an RS485 Modbus RTU/ASCII port.

Technical Specifications

Certifications & Standards

• CE
• cULus
• BTL
• EN 50470-1
• EN 50470-3
• IEC 60529
• IEC 61557-12
• IEC 62053-22
• IEC 62053-23
• IEC 62053-24
• IEC 62052-11
• IEC 62052-31
• ANSI C12.20

Selection Notes

The PM5560 adds dual daisy-chainable Ethernet ports and 63rd-harmonic resolution over the RS485-only PM5350, so it fits switchboards where a web server, onboard diagnostics or a Modbus TCP/BACnet gateway is already planned. Direct neutral-current and calculated ground-current monitoring on all four digital inputs supports branch-level WAGES metering without extra CTs. Where waveform capture or residual-current monitoring is also required, the PM5650/PM5660/PM5760 variants in the same enclosure add those functions on top of this base feature set.
