Part number
METSEPM5310R
Model no
PM5310R
$319.41 On request Dispatch — · From TürkiyeGet a Quote

Schneider Electric METSEPM5310R PowerLogic PM5310R Power Meter 31st Harmonic RJ45 LVCT Power Meter

PowerLogic PM5310R flush-mount power meter, Class 0.5S IEC 62053-22, 31st harmonic, RJ45 LVCT, RS485.

Rated operational voltage
760 V AC
Communication
Modbus RTU/ASCII RS485
Display
Monochrome graphic LCD, 128 x 128 pixels
Description

About the PM5310R

The Schneider Electric METSEPM5310R is a PowerLogic PM5310R flush-mount power meter built for 3-in-1 current transducer (LVCT) input over RJ45, measuring energy, active and reactive power, voltage, current, frequency, power factor, and harmonics up to the 31st order with Class 0.5S accuracy to IEC 62053-22. It reads out on a 96 x 96 mm monochrome graphic LCD, communicates over RS485 Modbus, and suits three-phase busbar monitoring.

Certifications & Standards

  • CE
  • cULus
  • IEC 61010-1
  • EN 50470-1
  • IEC 62053-22

Selection Notes

The METSEPM5310R swaps the PM5310's conventional CT terminals for an RJ45 input that takes a 3-in-1 LVCT such as the METSECTV35xxx block, cutting installation to a single cable per phase group on a busbar. Pick it over the standard PM5310 specifically when the current measurement point is an LVCT-compatible busbar rather than a cable requiring separate CTs.

Specification

Full specification

69 values · Last verified 30 Oct 2026

Main 4

Range PowerLogic
Product name PowerLogic PM5000
Product or component type Power meter
Device short name PM5310R

Complementary 34

Power quality analysis up to the 31st harmonic
Device application Power monitoring, Multi-tariff
Type of measurement Current, Voltage, Frequency, Power factor, Energy, Active and reactive power
[Us] rated supply voltage 90...450 V AC 45...65 Hz, 100...300 V DC
Network frequency 50 Hz, 60 Hz
[In] rated current 5 A, 1 A
type of network 1P + N, 3P, 3P + N
Maximum power consumption in VA 11 VA at 415 V
Ride-through time 80 ms 120 V AC typical, 100 ms 230 V AC typical, 100 ms 415 V AC typical, 50 ms 125 V DC typical
Display type Monochrome graphic LCD
Display resolution 128 x 128 pixels
Sampling rate 64 samples/cycle
Measurement current 10…9000 mA
Analogue input type Voltage (impedance 5 MOhm), Current 0.333 V (impedance 0.3 mOhm)
Measurement voltage 35…760 V AC 45...65 Hz between phases, 20…440 V AC 45...65 Hz between phase and neutral
Frequency measurement range 45…65 Hz
Number of inputs 2 digital
Measurement accuracy Active energy +/- 0.5 %, Reactive energy +/- 2 %, Active power +/- 0.5 %, Apparent power +/- 0.5 %, Frequency +/- 0.05 %, Power factor +/- 0.5, Current +/- 0.5 %, Voltage +/- 0.5 %, Apparent energy +/- 0.5 %, Reactive power +/- 2 %
Accuracy class Class 0.5S active energy conforming to IEC 62053-22
Number of outputs 2 digital
Information displayed Tariff (4)
Communication port protocol Modbus RTU and ASCII at 9.6, 19.2 and 38.4 kbauds even/odd or none - 2 wires, insulation 2500 V, JBUS
Communication port support RS485
Data recording Maintenance logs, Time stamping, Event logs, Data logs, Min/max of instantaneous values, Alarm logs
Memory capacity 256 kB
Connections - terminals Voltage circuit: screw terminal block4, Control circuit: screw terminal block2, Input/output circuit: screw terminal block6, Relay output: screw terminal block4, Ethernet network: RJ45 connector, Current transformer: RJ45 connector1
Mounting mode Flush-mounted
Mounting support Framework
Standards IEC 61557-12:2015, IEC 62053-22:2020, EN 50470-3, IEC 62053-24, UL 61010-1, EN 50470-1, IEC 60529, IEC 62053-23:2020, IEC 62052-11:2020, IEC 62052-31:2015
Product certifications CE conforming to IEC 61010-1, CULus conforming to UL 61010-1
Width 96 mm
Depth 72 mm
Height 96 mm
Net weight 430 g

Environment 7

Electromagnetic compatibility Electrostatic discharge - test level: 8 kV level 4 conforming to IEC 61000-4-2, Radiated radio-frequency electromagnetic field immunity test level 4 conforming to IEC 61000-4-3, Electrical fast transient/burst immunity test level 4 conforming to IEC 61000-4-4, Surge immunity test level 4 conforming to IEC 61000-4-5, Voltage dips and interruptions immunity test class B conforming to IEC 61000-4-11, Limits for harmonic current emissions class A conforming to IEC 61000-3-2, Conducted RF disturbances level 3 conforming to IEC 61000-4-6, Magnetic field at power frequency level 4 conforming to IEC 61000-4-8, Conducted and radiated emissions class B conforming to EN 55022, Limitation of voltage changes, voltage fluctuations and flicker in low-voltage conforming to IEC 61000-3-3, Radiated radio-frequency electromagnetic field immunity test level 3 conforming to IEC 61000-4-3, Voltage dips and interruptions immunity test conforming to IEC 61000-4-11
IP degree of protection IP54 display: conforming to IEC 60529, IP30 rear: conforming to IEC 60529
Relative humidity 5…95 % at 50 °C non-condensing
Pollution degree 2
Ambient air temperature for operation -25…70 °C
Ambient air temperature for storage -40…85 °C
Operating altitude <= 2000 m
Show all 69 specifications ↓ Show less ↑24 more values in Identification, Contractual warranty, Logistics.

Identification 7

Part number METSEPM5310R
Type designation PM5310R
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 16

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 13.000 cm
Package 1 Width 11.500 cm
Package 1 Length 12.500 cm
Package 1 Weight 416.000 g
Unit Type of Package 2 S03
Number of Units in Package 2 12
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 5.598 kg
Shipping weight 0.43 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for METSEPM5310R

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • UL
  • CE
  • IEC 61557-12:2015
  • IEC 62053-22:2020
  • EN 50470-3
  • IEC 62053-24
  • UL 61010-1
  • EN 50470-1
  • IEC 60529
  • IEC 62053-23:2020
  • IEC 62052-11:2020
  • IEC 62052-31:2015
Quick answers

Questions about the PM5310R

Which supply voltage is PM5310R rated for?

The rated operational voltage of PM5310R is 760 V AC.

What is the HS code of PM5310R for customs?

The tariff (HS) code on file for PM5310R is 902830.

Where does PM5310R ship from, and how fast?

PM5310R ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
