- Part number
- METSEPM5350
- Model no
- PM5350
Description
About the PM5350
About the PM5350
The Schneider Electric METSEPM5350 is a PowerLogic PM5350 flush-mount power and energy meter with Class 0.5S accuracy to IEC 62053-22. It measures voltage, current, frequency, power factor, active/reactive/apparent power and energy, and resolves harmonics up to the 15th order at 32 samples per cycle. Four digital inputs and two relay outputs are built in for alarming and load control over RS485 Modbus.
Certifications & Standards
- CE
- cULus
- IEC 61010-1
Selection Notes
The METSEPM5350 accepts a universal 85-265 V AC / 100-300 V DC supply and a selectable 1 A or 5 A CT input, so the same reference covers both direct low-voltage panel feeders and CT-metered branch circuits. Class 0.5S accuracy to IEC 62053-22 meets sub-metering and tenant-billing requirements, and the two relay outputs can drive an alarm or load-shed contact directly from a measured threshold without an external PLC. Choose the PM5560/PM5563 variants when 63rd-harmonic analysis or Ethernet communication is needed; the PM5350 covers RS485-only installations up to the 15th harmonic.
Specification
Full specification
Main 4
| Range | PowerLogic |
|---|---|
| Product name | PowerLogic PM5350 |
| Product or component type | Power meter |
| Device short name | PM5350 |
Complementary 32
| Power quality analysis | total demand distortion, total harmonic distortion |
|---|---|
| Device application | Power monitoring |
| Type of measurement | Current, Voltage, Frequency, Power factor, Energy, Apparent power, Active power, Reactive power |
| [Us] rated supply voltage | 85...265 V AC 45...65 Hz, 100...300 V DC |
| Network frequency | 50 Hz, 60 Hz |
| [In] rated current | 5 A, 1 A |
| type of network | 1P + N, 3P + N, 3P |
| Maximum power consumption in VA | 11.9 VA |
| Ride-through time | 100 ms 120 V AC typical, 400 ms 230 V AC typical, 50 ms 125 V DC typical |
| Display type | Monochrome graphic LCD |
| Display resolution | 6 lines |
| Sampling rate | 32 samples/cycle |
| Measurement current | 5…9000 mA |
| Analogue input type | Current 0.05...9 A (impedance <= 0.3 mOhm), Voltage (impedance 10 MOhm) |
| Measurement voltage | 35…480 V AC 45...65 Hz phase to phase, 20…277 V AC phase to neutral |
| Frequency measurement range | 45…70 Hz |
| Number of inputs | 4 digital |
| Measurement accuracy | Current +/- 0.3 %, Voltage +/- 0.3 %, Frequency +/- 0.05 %, Power factor +/- 0.005, Active energy +/- 0.5 %, Reactive energy +/- 2 %, Active power +/- 0.5 %, Apparent power +/- 0.5 %, Apparent energy +/- 0.5 %, Reactive power +/- 2 % |
| Accuracy class | Class 0.5S active energy conforming to IEC 62053-22, Class 0.5 active energy conforming to IEC 61557-12, Class 2 reactive energy conforming to IEC 62053-23, Class 2 reactive energy conforming to IEC 61557-12, Class 0.5 power conforming to IEC 61557-12 |
| Number of outputs | 2 relay |
| Communication port protocol | JBUS, Modbus RTU and ASCII at 9.6, 19.2 and 38.4 kbauds |
| Communication port support | Terminal block: RS485 |
| Data recording | Min/max of instantaneous values, Alarms |
| Connections - terminals | Voltage circuit: screw terminal block4, Control circuit: screw terminal block2, Current transformer: screw terminal block6, Input/output circuit: screw terminal block6, Relay output: screw terminal block4 |
| Mounting mode | Flush-mounted |
| Type of installation | For indoor use in a stationary panel |
| Standards | IEC 61010-1 |
| Product certifications | CE, CULus |
| Width | 96 mm |
| Depth | 44 mm |
| Height | 96 mm |
| Net weight | 0.25 kg |
Environment 8
| Electromagnetic compatibility | Limitation of voltage changes, voltage fluctuations and flicker in low-voltage conforming to IEC 61000-3-3, Electrostatic discharge conforming to IEC 61000-4-2, Susceptibility to electromagnetic fields conforming to IEC 61000-4-3, Electrical fast transient/burst immunity test conforming to IEC 61000-4-4, 1.2/50 µs shock waves immunity test conforming to IEC 61000-4-5, Conducted RF disturbances conforming to IEC 61000-4-6, Immunity to impulse waves conforming to IEC 61000-4-12, Conducted and radiated emissions class A conforming to EN 55011, Limits for harmonic current emissions conforming to IEC 61000-3-2 |
|---|---|
| Overvoltage category | III |
| IP degree of protection | IP30 rear: conforming to IEC 60529, IP54 display: conforming to IEC 60529 |
| Relative humidity | 5…95 % at 50 °C non-condensing |
| Pollution degree | 2 |
| Ambient air temperature for operation | -25…70 °C meter, -20…70 °C display, -25…-20 °C (with reduced performance) display |
| Ambient air temperature for storage | -40…85 °C |
| Operating altitude | <= 3000 m |
Show all 68 specifications ↓ Show less ↑24 more values in Identification, Contractual warranty, Logistics.
Identification 7
| Part number | METSEPM5350 |
|---|---|
| Type designation | PM5350 |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 16
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 11.200 cm |
| Package 1 Width | 12.500 cm |
| Package 1 Length | 12.700 cm |
| Package 1 Weight | 346.000 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 4.829 kg |
| Shipping weight | 0.25 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for METSEPM5350
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- IEC 61010-1
Quick answers
Questions about the PM5350
What is the rated current of PM5350?
The rated current of PM5350 is 1 A.
Which supply voltage is PM5350 rated for?
The rated operational voltage of PM5350 is 20–277 V AC.
What is the HS code of PM5350 for customs?
The tariff (HS) code on file for PM5350 is 902830.
Where does PM5350 ship from, and how fast?
PM5350 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
