- Part number
- METSEPM5340
- Model no
- PM5340
Description
About the PM5340
About the PM5340
The Schneider Electric METSEPM5340 is a PowerLogic PM5340 flush-mounted power meter that measures voltage, current, frequency, power factor, energy, and harmonics up to the 31st order with Class 0.5S accuracy per IEC 62053-22. It communicates over Modbus TCP/IP and BACnet/IP via a 10/100 Mbit/s Ethernet RJ45 port and offers 2 digital inputs plus 2 relay/digital outputs for alarms and control.
Certifications & Standards
- CE
- cULus
- IEC 61010-1
- UL 61010-1
- EN 50470-1
- EN 50470-3
- IEC 62053-22
- IEC 62053-23
- IEC 62053-24
- IEC 62052-11
- IEC 62052-31
- IEC 61557-12
- IEC 60529
Selection Notes
The PM5340's Class 0.5S accuracy to IEC 62053-22 combined with harmonic analysis up to the 31st order makes it suited to sub-metering and power-quality troubleshooting on the same connection, not just billing-grade energy totals. Dual native protocols - Modbus TCP/IP and BACnet/IP over the same RJ45 port - let it report into a building automation system and a dedicated energy platform without a protocol gateway. The 2 digital inputs and 2 configurable relay/digital outputs support local alarm or load-shedding logic directly at the meter, and the 256 kB log memory with four tariff schedules allows on-board multi-tariff billing without pulling raw data continuously.
Specification
Full specification
Main 4
| Range | PowerLogic |
|---|---|
| Product name | PowerLogic PM5000 |
| Product or Component Type | Power meter |
| Device short name | PM5340 |
Complementary 34
| Power quality analysis | up to the 31st harmonic |
|---|---|
| Device Application | Multi-tariff, Power monitoring |
| Type of measurement | Current, Voltage, Frequency, Power factor, Energy, Active and reactive power |
| [Us] rated supply voltage | 90...450 V AC 45...65 Hz, 100...300 V DC |
| Network Frequency | 60 Hz, 50 Hz |
| Line Rated Current | 5 A, 1 A |
| type of network | 3P, 1P + N, 3P + N |
| Maximum power consumption in VA | 11 VA 415 V |
| Ride-through time | 100 ms 120 V AC typical, 400 ms 230 V AC typical, 50 ms 125 V DC typical |
| Display Type | Monochrome graphic LCD |
| Display Resolution | 128 x 128 pixels |
| Sampling rate | 64 samples/cycle |
| Measurement current | 5…9000 mA |
| Analogue input type | Voltage (impedance 10 MOhm), Current (impedance <= 0.3 mOhm) |
| Measurement voltage | 35…760 V AC 45...65 Hz between phases, 20…400 V AC 45...65 Hz between phase and neutral |
| Frequency measurement range | 45…65 Hz |
| Number of inputs | 2 digital |
| Measurement accuracy | Active energy +/- 0.5 %, Reactive energy +/- 2 %, Active power +/- 0.5 %, Apparent power +/- 0.5 %, Frequency +/- 0.05 %, Power factor +/- 0.5, Current +/- 0.5 %, Voltage +/- 0.5 %, Apparent energy +/- 0.5 %, Reactive power +/- 2 % |
| Accuracy class | Class 0.5S active energy IEC 62053-22 |
| Number of Outputs | 2 relay, 2 digital |
| Information displayed | Tariff 4) |
| Communication port protocol | Modbus TCP/IP 10/100 Mbit/s 2500 V, BACnet IP |
| Communication port support | ETHERNET |
| Data recording | Data logs, Alarm logs, Time stamping, Event logs, Min/max of instantaneous values, Maintenance logs |
| Memory capacity | 256 kB |
| Connections - terminals | Voltage circuit screw terminal block4, Control circuit screw terminal block2, Current transformer screw terminal block6, Input/output circuit screw terminal block6, Relay output screw terminal block4, Ethernet network RJ45 connector |
| Mounting Mode | Flush-mounted |
| Mounting support | Framework |
| Standards | EN 50470-1, IEC 62053-24, IEC 60529, UL 61010-1, IEC 62053-22:2020, EN 50470-3, IEC 61557-12:2015, IEC 62053-23:2020, IEC 62052-11:2020, IEC 62052-31:2015 |
| Product certifications | CE conforming to IEC 61010-1, CULus conforming to UL 61010-1 |
| Width | 3.8 in (96 mm) |
| Depth | 2.8 in (72 mm) |
| Height | 3.8 in (96 mm) |
| Net Weight | 15.2 oz (430 g) |
Environment 7
| Electromagnetic compatibility | Limits for harmonic current emissions class A conforming to IEC 61000-3-2, Electrostatic discharge level 4 conforming to IEC 61000-4-2, Conducted RF disturbances level 3 conforming to IEC 61000-4-6, Magnetic field at power frequency level 4 conforming to IEC 61000-4-8, Conducted and radiated emissions class B conforming to EN 55022 |
|---|---|
| IP degree of protection | IP51 display: conforming to IEC 60529, IP30 rear: conforming to IEC 60529 |
| Relative humidity | 5…95 % 122 °F (50 °C) non-condensing |
| Pollution degree | 2 |
| Ambient air temperature for operation | -13…158 °F (-25…70 °C) meter, -4…158 °F (-20…70 °C) display, -13…-4 °F (-25…-20 °C) with reduced performance) display |
| Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Operating altitude | <= 9842.52 ft (3000 m) |
Show all 59 specifications ↓ Show less ↑14 more values in Identification, Contractual warranty, Logistics.
Identification 8
| Part number | METSEPM5340 |
|---|---|
| Type designation | PM5340 |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 3606480624520 |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 5
| Country of origin | IN |
|---|---|
| Shipping weight | 0.43 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for METSEPM5340
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- UL
- CE
- EN 50470-1
- IEC 62053-24
- IEC 60529
- UL 61010-1
- IEC 62053-22:2020
- EN 50470-3
- IEC 61557-12:2015
- IEC 62053-23:2020
- IEC 62052-11:2020
- IEC 62052-31:2015
Quick answers
Questions about the PM5340
What is the rated current of PM5340?
The rated current of PM5340 is 5 A.
Which supply voltage is PM5340 rated for?
The rated operational voltage of PM5340 is 20–400 V AC.
What is the HS code of PM5340 for customs?
The tariff (HS) code on file for PM5340 is 902830.
What is the EAN of PM5340?
The EAN (GTIN) of PM5340 is 3606480624520.
Where does PM5340 ship from, and how fast?
PM5340 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
