Schneider Electric METSEPM2230 EasyLogic PM2230 Power Meter Class 0.5S LCD RS485 Modbus Power Meter

% $-172.99
Schneider Electric METSEPM2230 EasyLogic PM2230 power meter with LCD and RS485
Schneider Electric METSEPM2230 EasyLogic PM2230 power meter with LCD and RS485

Schneider Electric METSEPM2230 EasyLogic PM2230 Power Meter Class 0.5S LCD RS485 Modbus Power Meter

Brand: Schneider Electric
Reference No: METSEPM2230
Catalog No: METSEPM2230
Tariff Code (HS): 902830
Rated Current: 5 A
Rated Voltage: 480 V
Communication: Modbus RTU RS485
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$172.99

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric METSEPM2230 is an EasyLogic PM2230 power and energy meter, measuring active, reactive, and apparent power and energy with Class 0.5S accuracy to IEC 62053-22. It reads voltage, current, frequency, power factor, and total harmonic distortion up to the 31st harmonic on a 96 x 96 mm bezel with a backlit 128 x 128 pixel LCD, and communicates over RS485 Modbus RTU.

Technical Specifications

Reference METSEPM2230
Brand Schneider Electric
Range EasyLogic PM2200
Product type Power meter
Accuracy class Class 0.5S active energy IEC 62053-22, Class 1 reactive energy IEC 62053-24, Class 5 harmonic distortion
Measurement accuracy Active power +/- 0.5 %, voltage +/- 0.5 %, current +/- 0.5 %, frequency +/- 0.05 %
Rated supply voltage (Us) 80...277 V AC 45...65 Hz or 100...277 V DC
Rated current (In) 1 A / 5 A
Network frequency 50 Hz / 60 Hz
Measurement voltage 35...480 V AC between phases, 20...277 V AC phase to neutral
Power quality analysis Total harmonic distortion, up to the 31st harmonic
Sampling rate 64 samples/cycle
Display type Backlit monochrome LCD, 128 x 128 pixels
Communication Modbus RTU, RS485 screw terminal block
Expansion 1 optional analog or digital I/O module
Data recording Power logs, energy consumption logs, time stamping, min/max for 8 parameters
Mounting mode Clip-on
Dimensions (W x H x D) 96 x 96 x 76 mm
IP degree of protection IP54 front, IP30 body
Net weight 300 g

Certifications & Standards

  • CE
  • cULus
  • RCM
  • EAC

Selection Notes

The METSEPM2230 steps up to Class 0.5S active energy accuracy and 31st-harmonic analysis, and it is the only LCD PM2200 variant that accepts the optional analog or digital I/O expansion module for WAGES monitoring. Pick it over the PM2220 when the application needs revenue-grade accuracy or an extra I/O point, not just RS485 connectivity.

Technical Details

Short Description
EasyLogic PM2230 power meter, Class 0.5S IEC 62053-22, 31st harmonic THD, LCD display, RS485 Modbus.
Rated Current (Ampere)
5 A
Rated Voltage (VAC)
480 V
Mounting Type
Clip-on
Protection Type
IP54 front / IP30 body
Catalog No
METSEPM2230
Delivery Date (Days)
30 days
Model Number
PM2230
Tariff Code
902830
