The Schneider Electric LV432457 is a Vigi connection adaptor that lets a 4-pole insulation monitoring module be fitted on a 3-pole ComPact NSX400/630 moulded case circuit breaker, rated to the breaker's 630 A frame. It mounts directly on the device terminals so the Vigi module can detect and indicate an insulation drop.
LV432457 is a mechanical adaptation part, not a Vigi module itself: it is needed only when a 4-pole insulation monitoring module is specified on a 3-pole ComPact NSX400/630 breaker rather than a matching 4-pole breaker. It terminates directly on the breaker connection studs with no separate wiring.
| Range of product | ComPact NSX400...630 |
|---|---|
| Range | ComPact |
| Device short name | Vigi 4P/3P adaptor |
| Product or component type | Vigi adaptor |
| Device application | Connection |
| Range compatibility | ComPact ComPact NSX400, ComPact ComPact NSX630 |
| Accessory / separate part category | Adaptation accessory |
| Poles description | 4P, 3P |
| [In] rated current | 630 A |
| Warranty (in months) | 18 |
|---|
| Part number | LV432457 |
|---|---|
| Type designation | Vigi 4P/3P adaptor |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.0 cm |
| Package 1 Width | 11.0 cm |
| Package 1 Length | 19.0 cm |
| Package 1 Weight | 54.0 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 15.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 1.103 kg |
| Shipping weight | 0.054 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
No documents are on file for this part yet.
Ask us for the datasheetThe tariff (HS) code on file for Vigi 4P/3P adaptor is 853890.
Vigi 4P/3P adaptor ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
