Part number
LV426846
Model no
MX
$149.90 On request Dispatch — · From TürkiyeGet a Quote
Schneider ComPacT NSX

Schneider Electric LV426846 ComPacT NSXm MX Shunt Trip Release 380-415 V AC Circuit Breaker Accessory

MX shunt trip release for ComPacT NSXm/PowerPact B, 380-415 V AC 50 Hz control voltage, opens at 70% Un.

Rated operational voltage
380–415 V AC
EAN
3606485413099
Description

About the MX

The Schneider Electric LV426846 is a standard MX shunt trip release for ComPacT NSXm and PowerPact B moulded case circuit breakers, rated 380-415 V AC 50 Hz (also available as 440-480 V AC 60 Hz on this same reference). It trips the breaker on command for emergency-off or remote-opening duty once the control voltage exceeds 70% of its rated value, with a response time under 50 ms.

Selection Notes

LV426846 suits ComPacT NSXm and PowerPact B breakers wired to 380-415 V AC 50 Hz control circuits; the same body also covers 440-480 V AC 60 Hz supplies. For breakers running on 220/240 V AC or lower control circuits, choose the lower-voltage shunt trip variant instead. The one-click spring-terminal body mounts on the breaker's front face, so wiring the emergency-off or remote-opening circuit needs no screw tools and the coil position stays visible for inspection. ComPacT NSXm and PowerPact B accept either one MX or one MN coil, never both at once.

Specification

Full specification

28 values · Last verified 30 Oct 2026

Main 9

Range ComPact
Range of Product ComPacT NSXm
Device short name MX
Product or Component Type Voltage release
Device Application Control
Voltage release type Opening coil, Shunt trip release
Control Type Standard
[Uc] control circuit voltage 380...415 V AC 50 Hz, 440...480 V AC 60 Hz
Range compatibility ComPact ComPacT NSXm, ComPact ComPact NSXm, PowerPact PowerPact B

Complementary 5

Operating threshold 0.7 Un opening
Response time < 50 ms
Control signal type Impulse, Maintained
Impulse duration >= 20 ms
Auxiliary connection terminal spring

Contractual warranty 1

Warranty (in months) 18
Show all 28 specifications ↓ Show less ↑13 more values in Identification, Logistics.

Identification 8

Part number LV426846
Type designation MX
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 3606485413099

Logistics 5

Country of origin FR
Shipping weight 0.061 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for LV426846

No documents are on file for this part yet.

Ask us for the datasheet
Quick answers

Questions about the MX

Which supply voltage is MX rated for?

The rated operational voltage of MX is 380–415 V AC.

What is the HS code of MX for customs?

The tariff (HS) code on file for MX is 853890.

What is the EAN of MX?

The EAN (GTIN) of MX is 3606485413099.

Where does MX ship from, and how fast?

MX ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
