The Schneider Electric G20PLUGFASB2 is a set of 2 plug-in base insulators for the GoPact MCCB 200, fitting both 3-pole and 4-pole plug-in versions. Mounted upstream or downstream of the plug-in base, the insulators protect against direct contact with the power circuit at the base terminals and give IP40 degree of protection to IEC 60529.
Order the G20PLUGFASB2 alongside a G20PBASE3P or G20PBASE4P plug-in base to insulate the exposed power terminals on a plug-in GoPact MCCB 200 installation - the shield and spreader accessories used on fixed-mount breakers do not fit the plug-in base geometry. As a set of 2, order enough sets to cover every insulation position the base requires.
| Range of product | GoPact MCCB |
|---|---|
| Product or component type | Insulator |
| Device application | Insulation |
| Range compatibility | GoPact MCCB 200 |
| Poles description | 3P, 4P |
| Quantity | 2 |
| Localisation on device | Upstream, Downstream |
|---|---|
| Accessory / separate part category | Spare part |
| Warranty (in months) | 18 |
|---|
| Part number | G20PLUGFASB2 |
|---|---|
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1 cm |
| Package 1 Width | 28 cm |
| Package 1 Length | 19.5 cm |
| Package 1 Weight | 0.15 kg |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 4 kg |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 384 |
| Package 3 Height | 149 cm |
| Package 3 Width | 60 cm |
| Package 3 Length | 80 cm |
| Package 3 Weight | 72.6 kg |
| Shipping weight | 0.15 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
No documents are on file for this part yet.
Ask us for the datasheetThe tariff (HS) code on file for G20PLUGFASB2 is 853890.
G20PLUGFASB2 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
