EasyPact CVSSchneider Electric E100S3NAFM EasyPact CVS1000NA 3P 1000 A 440 V AC Switch Disconnector
Schneider Electric E100S3NAFM, EasyPact CVS1000NA, 3P 1000 A switch-disconnector, 440 V AC, 40 kA Icm
Description
About the CVS1000NA
About the CVS1000NA
The Schneider Electric E100S3NAFM is a 1000 A, 3-pole EasyPact CVS1000NA switch-disconnector for manual isolation on low-voltage distribution boards. Rated 440 V AC with a 40 kA making capacity (Icm) and 20 kA/0.5 s short-time withstand (Icw), it covers utilisation categories AC-22 and AC-23A under IEC 60947-3.
Certifications & Standards
- CCC
- CB
- CE
- IEC 60947-3
Selection Notes
E100S3NAFM is a manual isolating switch, not a protective device -- pair it with a separate fuse or breaker upstream for short-circuit protection, since its 40 kA Icm rating covers making onto a fault but the device itself carries no trip unit. The 3-pole version switches the three phase conductors only, matching a feeder where the neutral is bonded upstream and does not need to be opened for isolation. At 1000 A it shares the same CVS1000 frame footprint as the equivalent E100F/H/N circuit breakers, so it drops into the same switchboard cutout when a project calls for a lockable isolation point instead of a protective breaker.
Specification
Full specification
Main 6
| Range | EasyPact |
|---|---|
| Range of product | EasyPact CVS |
| Product or component type | Switch disconnector |
| Device short name | CVS1000NA |
| Device application | Low voltage electrical distribution |
| Poles description | 3P |
Complementary 20
| [Ue] rated operational voltage | 440 V AC 50/60 Hz |
|---|---|
| [In] rated current | 1000 A at 50 °C |
| Breaking capacity code | NA |
| Network type | AC |
| Network frequency | 50/60 Hz |
| [Ui] rated insulation voltage | 440 V AC 50/60 Hz conforming to IEC 60947-3 |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to IEC 60947-3 |
| With switched-off indicator | True |
| Control type | Rotary handle, Toggle |
| Utilisation category | AC-22, AC-23A |
| [Icm] rated short-circuit making capacity | 40 kA (Icm) at 440 V AC 50/60 Hz |
| [Icw] rated short-time withstand current | 20 kA 0.5 s conforming to IEC 60947-3, 15 kA 1 s conforming to IEC 60947-3 |
| Mechanical durability | 5000 cycles |
| Electrical durability | 2000 cycles for AC at 440 V 50/60 Hz |
| Suitability for isolation | Yes conforming to IEC 60947-3 |
| Connection pitch | 70 mm |
| Mounting mode | Fixed |
| Mounting support | Backplate |
| Contact position indicator | Yes |
| Net weight | 14 kg |
Environment 12
| IP degree of protection | IP40 conforming to IEC 60529 |
|---|---|
| IK degree of protection | IK07 conforming to IEC 62262 |
| Relative humidity | 0…95 % |
| Operating altitude | 0...2000 m without derating, 2000...5000 m with derating |
| Height | 327 mm |
| Width | 210 mm |
| Depth | 147 mm |
| Standards | IEC 60947-3 |
| Product certifications | CCC, CB, CE |
| Pollution degree | 3 conforming to IEC 60664-1 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
Show all 56 specifications ↓ Show less ↑18 more values in Identification, Contractual warranty, Logistics.
Identification 7
| Part number | E100S3NAFM |
|---|---|
| Type designation | CVS1000NA |
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
Contractual warranty 1
| Warranty (in months) | 18 |
|---|
Logistics 10
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 29.5 cm |
| Package 1 Width | 39.6 cm |
| Package 1 Length | 59.6 cm |
| Package 1 Weight | 14.8 kg |
| Shipping weight | 14.0 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for E100S3NAFM
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- CCC
- IEC 60947-3
Quick answers
Questions about the CVS1000NA
What is the rated current of CVS1000NA?
The rated current of CVS1000NA is 1000 A.
Which supply voltage is CVS1000NA rated for?
The rated operational voltage of CVS1000NA is 440 V AC.
What is the HS code of CVS1000NA for customs?
The tariff (HS) code on file for CVS1000NA is 853650.
Where does CVS1000NA ship from, and how fast?
CVS1000NA ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
