ABB 2CDS211103R0204 SH201-C20NA 1P+N 20A 6kA C-Curve 230/400V AC Miniature Circuit Breaker

The ABB SH201-C20NA miniature circuit breaker (2CDS211103R0204) is a 1P+N, 20A, C-curve MCB from the SH200 series, rated at 230/400V AC with a breaking capacity of 6 kA. Designed for reliable overcurrent and short-circuit protection in residential and light commercial installations, the SH201-C20NA delivers compact, space-saving performance in a 35mm-wide DIN rail-mounted housing that fits standard distribution boards.

Technical Specifications

Certifications & Standards

• IEC/EN 60898-1: International and European standard for household and similar circuit breakers
• IEC 60898-1: IEC standard for miniature circuit breakers for overcurrent protection
• EN 60898-1: European harmonised standard for circuit breakers
• IEC/EN60898-1: Combined IEC/EN compliance designation
• IEC 60898: Core IEC standard series for circuit breaker performance
• IEC 60068-2: Environmental testing standard for industrial electrical equipment
• EN45555: General methods for assessing the ability of energy-related products to be repaired, reused, upgraded, and recycled
• EN45555-92: Extended environmental sustainability assessment standard
• EN60664: Insulation coordination for equipment within low-voltage systems
• CE: Conformité Européenne — meets EU safety, health, and environmental requirements
• REACH: Compliant with EU REACH regulation on chemical substances
• RoHS: Restriction of Hazardous Substances — compliant with EU RoHS directive
• WEEE: Waste Electrical and Electronic Equipment directive compliance
• SNI: Indonesian National Standard certification
