ABB 2CDS211103R0324 SH201-C32NA 1P+N 32A 6kA C-Curve 230/400V AC Miniature Circuit Breaker

The ABB SH201-C32NA (SKU: 2CDS211103R0324) is a 1P+N 32A C-curve miniature circuit breaker (MCB) from the SH200 series, rated at 230/400V AC with a breaking capacity of 6 kA per IEC/EN 60898-1. Designed for residential and light commercial distribution boards, the SH201-C32NA provides reliable overcurrent and short-circuit protection in a compact 35mm DIN rail mount form factor. Weighing just 0.21 kg, it is ideal for space-constrained control panels and consumer unit installations.

Technical Specifications

Certifications & Standards

• IEC/EN 60898-1: International and European standard for miniature circuit breakers for household and similar installations
• IEC 60898-1: IEC standard for circuit breakers for overcurrent protection in household and similar installations
• EN 60898-1: European harmonised standard for miniature circuit breakers
• IEC 60898: Broader IEC framework standard for circuit breaker performance and testing
• IEC 60068-2: Environmental testing standard covering mechanical and climatic durability
• IEC 60715: Standard for DIN rail mounting dimensions for modular electrical equipment
• EN 45555: European standard for general methods for the assessment of the ability to recover raw materials from electrical and electronic equipment
• EN 45555-92: Supplementary clause of EN 45555 covering product-specific recovery assessments
• EN 60664: Insulation coordination standard for equipment within low-voltage systems
• CE: European Conformity marking confirming compliance with applicable EU directives
• RoHS: Restriction of Hazardous Substances — free from restricted materials including lead, mercury, and cadmium
• REACH: European chemicals regulation compliance confirming no substances of very high concern above threshold limits
• WEEE: Waste Electrical and Electronic Equipment directive compliance for end-of-life recycling and recovery

Applications & Use Cases

• Residential distribution boards and consumer units requiring 1P+N protection
• Light commercial electrical installations with mixed single-phase and neutral circuits
• Final circuits in DIN rail mounted control panels and switchboards
• General-purpose overcurrent and short-circuit protection for resistive and inductive loads (C-curve)
• Retrofit or upgrade of legacy breakers where compact 35mm width is required
