- Part number
- 2CDS211103R0104
- Model no
- SH201-C10NA
In stock · 50+
Dispatch
Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days.
· From Türkiye
0
- CE
- RoHS
ABB 2CDS211103R0104 SH201-C10NA 1P+N 10A 6kA C-Curve 230/400V Miniature Circuit Breaker
Other ratings in ABB SH200
All 9 ratings ↓
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 6 | 2CDS211103R0064 | In stock | $16.89 | |
| 10 | 2CDS211103R0104This part | In stock | $14.08 | |
| 16 | 2CDS211103R0164 | In stock | $14.08 | |
| 20 | 2CDS211103R0204 | In stock | $14.08 | |
| 25 | 2CDS211103R0254 | In stock | $14.08 |
Description
About the SH201-C10NA
About the SH201-C10NA
The ABB SH201-C10NA miniature circuit breaker (MCB), SKU 2CDS211103R0104, is a 1P+N single-pole-plus-neutral device rated at 10A with a C-curve trip characteristic and 6kA breaking capacity at 230/400V AC. Part of ABB's SH200 series, the SH201-C10NA is engineered for reliable overcurrent and short-circuit protection in residential, commercial, and light industrial distribution boards where space efficiency and dependable performance are essential.
Certifications & Standards
- IEC/EN 60898-1: International and European standard for miniature circuit breakers for overcurrent protection
- IEC 60898-1: IEC standard for circuit breakers used in domestic and similar installations
- EN 60898-1: European harmonised standard for miniature circuit breakers
- IEC 60898: General series IEC standard for overcurrent protective circuit breakers
- IEC 60068-2: Environmental testing standard covering climatic and mechanical durability
- EN 45555: European standard for general requirements on sustainable electrical and electronic products
- EN 45555-92: Extended sustainability requirements for electrical and electronic equipment
- EN 60664: Insulation coordination for equipment within low-voltage systems
- SNI: Indonesian National Standard certification for market compliance
- CE: European Conformity marking confirming compliance with EU directives
- RoHS: Restriction of Hazardous Substances — compliant, free from restricted materials
- REACH: EU chemical safety regulation compliance
- WEEE: Waste Electrical and Electronic Equipment directive compliance for responsible disposal
Specification
Full specification
Technical 19
| Dielectric Test Voltage | 50 / 60 Hz - 1 min 2 kV |
|---|---|
| Power Supply Connection | Arbitrary |
| Contact Position Indication | ON / OFF |
| Energy Limiting Class | 3 |
| Electrical Endurance | 20000 AC cycle |
| Mechanical Endurance | 20000 cycle |
| Number of Protected Poles | 1 |
| Number of Poles | 1P+N |
| Position of Neutral Terminals | Right |
| Tightening Torque | 2 N·m |
| Screw Terminal Type | Cage Terminal |
| Actuator Marking | I / O |
| Actuator Material | Insulation Group II, Black, Sealable |
| Recommended Screw Driver | Pozidriv 2 |
| Accessories Available | No |
| Connecting Capacity | Conductor 25 / 25 mm², Flexible with Ferrule 0.75 ... 16 mm², Flexible 0.75 ... 16 mm², Rigid 0.75 ... 25 mm², Stranded 0.75 ... 25 mm² |
| Installation Size | acc. to DIN 43880 1 |
| Terminal Type | Screw Terminals |
| Actuator Type | Toggle |
Electrical 11
| Tripping Characteristic | C |
|---|---|
| Rated Operational Voltage | acc. to IEC 60898-1 230 V |
| Operational Voltage | Maximum (Incl. Tolerance) 253 V AC, Minimum 12 V AC |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 440 V |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV, at 2000 m 5 kV, at Sea Level 6.2 kV |
| Input Voltage Type | AC |
| Rated Current (In) | 10 A |
| Rated Short-Circuit Capacity | (AC) 6 kA, (230 / 400 V AC) 10 kA, (230 V AC) 6 kA, (230 V) 6 kA |
| Rated Frequency (f) | 50 / 60 Hz |
| Power Loss | 4.2 W, at Rated Operating Conditions per Pole 2.1 W |
| Overvoltage Category | III |
Design 1
| Housing Material | Insulation Group II, RAL 7035 |
|---|
Show all 73 specifications ↓ Show less ↑42 more values in Identification, Material Compliance, Environmental, Dimensions, Installation, External Classifications and Standards, Logistics.
Identification 11
| Part number | 2CDS211103R0104 |
|---|---|
| Type designation | SH201-C10NA |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 4016779630832 |
| ETIM class | EC000042 |
| eCl@ss | 27141901 |
| Package Level 1 Units | carton 5 piece |
| Package Level 1 Gross Weight | 1.025 kg |
Material Compliance 6
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|---|
| RoHS Date | 20260312 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20260312 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Business |
Environmental 7
| Ambient Air Temperature | Operation -25 ... +55 °C, Storage -40 ... +70 °C |
|---|---|
| Reference Ambient Air Temperature | 30 °C |
| Degree of Protection | IP20, Enclosure with Cover IP40 |
| Pollution Degree | 2 |
| Environmental Conditions | 28 cycles, with 55 °C / 90-96 %, and 25 °C / 95-100 % |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 5g 5 ... 150 ... 5 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g 2 shocks 13 ms |
Dimensions 7
| Width in Number of Modular Spacings | 2 |
|---|---|
| Product Net Width | 35 mm |
| Product Net Height | 85 mm |
| Product Net Depth / Length | 69 mm |
| Product Net Weight | 0.197 kg |
| Pole Net Weight | 0.125 kg |
| Built-In Depth (t2) | 69 mm |
Installation 2
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 |
|---|---|
| Mounting Position | any |
External Classifications and Standards 5
| ETIM 10 | EC000042 - Miniature circuit breaker (MCB) |
|---|---|
| UNSPSC | 39121603 |
| eClass | V11.0 : 27141901 |
| Standards | IEC/EN 60898-1 |
| Certification Agency | EN, IEC |
Logistics 4
| Shipping weight | 1.29 kg |
|---|---|
| Ships from | Türkiye |
| Dispatch | 11 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 2CDS211103R0104
No documents are on file for this part yet.
Ask us for the datasheet
Other ratings
All 9 ratings in ABB SH200
ABB ABB SH200 series page →
| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 6 A | 2CDS211103R0064 | SH201-C6NA | In stock | $16.89 | |||
| 10 A | 2CDS211103R0104 This part | SH201-C10NA | In stock | $14.08 | |||
| 16 A | 2CDS211103R0164 | SH201-C16NA | In stock | $14.08 | |||
| 20 A | 2CDS211103R0204 | SH201-C20NA | In stock | $14.08 | |||
| 25 A | 2CDS211103R0254 | SH201-C25NA | In stock | $14.08 | |||
| 32 A | 2CDS211103R0324 | SH201-C32NA | In stock | $17.60 | |||
| 40 A | 2CDS211103R0404 | SH201-C40NA | In stock | $18.30 | |||
| 50 A | 2CDS211103R0504 | SH201-C50NA | In stock | $21.11 | |||
| 63 A | 2CDS211103R0634 | SH201-C63NA | In stock | $23.93 |
Certifications
Certifications and standards
- CE
- RoHS
- IEC/EN 60898-1
Quick answers
Questions about the SH201-C10NA
What is the rated current of SH201-C10NA?
The rated current of SH201-C10NA is 10 A.
Which supply voltage is SH201-C10NA rated for?
The rated operational voltage of SH201-C10NA is 230–400 V AC.
What is the HS code of SH201-C10NA for customs?
The tariff (HS) code on file for SH201-C10NA is 853620.
What is the EAN of SH201-C10NA?
The EAN (GTIN) of SH201-C10NA is 4016779630832.
Where does SH201-C10NA ship from, and how fast?
SH201-C10NA ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
