Tmax XT5ABB 1SDA104930R1 YO-C XT5 W 110..240 Vac-110..250 Vdc Switch Spool for Moulded Case Circuit Breaker Withdrawable
Description
About the YO-C
About the YO-C
The ABB 1SDA104930R1 YO-C XT5 W 110..240 Vac-110..250 Vdc is a switch spool (shunt opening release) designed for ABB Tmax XT5 withdrawable power circuit breakers. The YO-C XT5 W 110..240 Vac-110..250 Vdc accepts a wide dual-voltage input range — 110 to 240 V AC or 110 to 250 V DC — enabling reliable remote tripping across diverse control power supplies in industrial and commercial electrical installations. Weighing only 0.17 kg, this compact accessory integrates directly into the Tmax XT5 withdrawable breaker frame to provide electrically commanded opening for protection and control applications.
Certifications & Standards
- RoHS: Compliant with EU Restriction of Hazardous Substances directive
- REACH: Compliant with EU REACH chemical regulation
- EU Directive 2011/65/EU & Amendment 2015/863: Compliant as of July 22, 2019
- IEC 60947-2 / UL 489: Meets international and North American circuit breaker standards
- IEC 60947: Compliant with IEC low-voltage switchgear and controlgear standard
- CE: Carries CE marking for EU market conformity
- WEEE: Registered under EU Waste Electrical and Electronic Equipment directive
Applications & Use Cases
- Remote electrical trip command for Tmax XT5 withdrawable power circuit breakers in MCC and switchgear panels
- Integration with PLC or relay-based protection systems requiring shunt trip functionality
- Industrial automation control panels where wide-range AC/DC control voltage is required
- Building services and infrastructure distribution boards requiring remote breaker opening
- Emergency stop and interlock circuits in process plants and industrial facilities
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 1
| Product Net Weight | 0.17 kg |
|---|
Additional Information 5
| Product Main Type | Accessories for Tmax XT |
|---|---|
| Product Name | Accessory |
| Product Type | Accessory |
| Suitable For | XT5 |
| Suitable for Product Class | SACE Tamx XT |
Show all 37 specifications ↓ Show less ↑30 more values in Identification, Technical, External Classifications and Standards, Logistics.
Identification 11
| Part number | 1SDA104930R1 |
|---|---|
| Type designation | YO-C |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 8015644070229 |
| ETIM class | EC002483 |
| eCl@ss | 27370421 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
Technical 5
| Configuration Type | Loose or configurable |
|---|---|
| Current Type | AC/DC |
| Order Multiple | 1 piece |
| Rated Voltage (Ur) | 110...240 V AC, 110...250 V DC |
| Standards | IEC60947-2, UL489 |
External Classifications and Standards 4
| ETIM 10 | EC002483 - Switch spool for power circuit breaker |
|---|---|
| UNSPSC | 39121601 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370421 |
Logistics 10
| Package Level 1 Units | box 1 piece |
|---|---|
| Package Level 1 Width | 110 mm |
| Package Level 1 Height | 60 mm |
| Package Level 1 Depth / Length | 140 mm |
| Package Level 1 Gross Weight | 0.2 kg |
| Package Level 1 EAN | 8015644070229 |
| Shipping weight | 0.2 kg |
| Ships from | Türkiye |
| Dispatch | 9 Nov |
| Stock | Critical stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SDA104930R1
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- CE
- RoHS
- IEC60947-2
- UL489
Quick answers
Questions about the YO-C
What is the HS code of YO-C for customs?
The tariff (HS) code on file for YO-C is 85389099.
What is the EAN of YO-C?
The EAN (GTIN) of YO-C is 8015644070229.
Where does YO-C ship from, and how fast?
YO-C ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
