ABB 1SDA071032R1 E2.2N 2000 Ekip Dip LSI 3p F HR 2000A 3P 66kA Fixed Air Circuit Breaker

The ABB 1SDA071032R1 — catalog number E2.2N 2000 Ekip Dip LSI 3p F HR — is a 2000 A, 3-pole fixed-mounted air circuit breaker from the SACE Emax2 E2.2 series, rated for a breaking capacity of 66 kA at 400 V AC. Designed for transformer, generator, and installation protection, it features the Ekip Dip LSI (Long-time, Short-time, Instantaneous) protection trip unit and HR (High Rating) withdrawable fixed frame, making it a premier choice for main distribution boards and critical power infrastructure.

Technical Specifications

Certifications & Standards

• CE: Complies with applicable EU directives for electrical equipment
• IEC: Meets IEC standards for air circuit breakers and low-voltage switchgear
• UL 2799: Listed under UL 2799 for electrical systems performance
• VDE: Certified to German VDE electrical engineering standards
• ATEX: Assessed for use in potentially explosive atmospheres
• CSA: Certified by the Canadian Standards Association
• RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances
• REACH: Compliant with EU REACH regulation on chemical substances
• EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Compliant with the updated RoHS substance list
• WEEE: Registered under the Waste Electrical and Electronic Equipment directive

Applications & Use Cases

• Main incoming protection for transformer secondary feeders
• Generator circuit protection in standby and prime power systems
• Bus-tie and outgoing feeder protection in main low-voltage switchboards
• Industrial facility power distribution panels requiring high breaking capacity
• Data centre and critical infrastructure power distribution
• Marine and offshore power distribution systems (subject to project-level approval)
