ABB 1SDA067446R1 XT1S 160 TMD 160-1600 4p F F InN=100% 4-Pole 160A Fixed Moulded Case Circuit Breaker

The ABB 1SDA067446R1 XT1S 160 TMD 160-1600 4p F F InN=100% is a 4-pole, 160 A fixed moulded-case power circuit breaker from the Tmax XT1 series, engineered for transformer, generator, and installation protection in demanding industrial environments. Featuring a thermal-magnetic TMD trip unit with a current setting range of 160–1600 A and 100 % neutral conductor protection (InN=100%), this breaker delivers precise overload and short-circuit protection across all four poles. Its compact fixed design — just 101.6 mm × 130 mm × 70 mm and 1.4 kg — makes it ideal for space-constrained switchgear panels and distribution boards.

Technical Specifications

Certifications & Standards

• IEC 60947-2: Low-voltage switchgear and controlgear — circuit breakers
• CE: Conformité Européenne — meets applicable EU safety, health, and environmental requirements
• ATEX: Certified for use in potentially explosive atmospheres
• VDE: Verified to German electrotechnical standards (Verband der Elektrotechnik)
• RoHS: Restriction of Hazardous Substances — compliant per EU Directive 2011/65/EU
• REACH: Registration, Evaluation, Authorisation and Restriction of Chemicals — EU compliant
• EU Directive 2011/65/EU & Amendment 2015/863 (July 22, 2019): Substance restriction update compliance confirmed
• EN 45555: General methods for the assessment of the ability to recover raw materials from electrical and electronic equipment
• UL 2799: Standard for electrical systems for construction and demolition equipment
• WEEE: Waste Electrical and Electronic Equipment Directive — product registered for proper end-of-life recycling

Applications & Use Cases

• Transformer protection: Guards LV windings against overload and downstream short-circuit faults with full 4-pole isolation including neutral.
• Generator circuit protection: Suitable for stand-by and prime power generator output breakers where complete pole-and-neutral switching is required.
• Main installation protection: Acts as the incoming circuit breaker in industrial switchboards, motor control centres, and building distribution panels.
• Hazardous area switchgear: ATEX certification permits deployment in Zone 2 / Zone 22 classified installations when housed in a suitable enclosure.
• Industrial automation panels: Compact fixed format fits standard DIN-rail or busbar assemblies inside machine control cabinets.
