ABB 1SDA067442R1 XT1S 160 TMD 100-1000 4p F F 4-Pole 100-1000A Fixed Moulded Case Circuit Breaker

The ABB 1SDA067442R1 XT1S 160 TMD 100-1000 4p F F is a 4-pole fixed-mount moulded case power circuit breaker from the Tmax XT1 series, delivering adjustable thermal-magnetic protection across a 100–1000 A current range. Designed for transformer, generator, and installation protection in industrial control panels, the XT1S 160 TMD 100-1000 4p F F combines compact dimensions (101.6 mm × 130 mm × 70 mm) with robust breaking performance and full IEC 60947-2 compliance.

Technical Specifications

Certifications & Standards

• CE: Conforms to European Union product safety and regulatory requirements
• IEC 60947-2: Low-voltage switchgear and controlgear — circuit breakers
• VDE: Certified to German electrotechnical standards (Verband der Elektrotechnik)
• ATEX: Approved for use in potentially explosive atmospheres (EU Directive 2014/34/EU)
• RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances
• REACH: Complies with EU REACH regulation on chemical substance safety
• EU Directive 2011/65/EU: RoHS directive restricting hazardous substances in electrical equipment
• Amendment 2015/863: RoHS amendment extending restricted substance scope
• EN 45555: General methods for the assessment of the recyclability and recoverability of energy-related products
• UL 2799: Standard for electrical systems for stationary fuel cell power systems
• WEEE: Waste Electrical and Electronic Equipment directive compliance for responsible end-of-life disposal

Applications & Use Cases

• Transformer primary and secondary side overcurrent and short-circuit protection
• Generator output protection in standby and prime power installations
• Main incomer and feeder protection in industrial switchboards and distribution panels
• Motor feeder branch circuit protection in heavy-duty industrial automation environments
• Control panel protection in manufacturing, process, and building automation systems
• Applications requiring ATEX-rated circuit protection in hazardous area installations
