ABB 1SDA067424R1 XT1N 160 TMD 100-1000 4p F F 4-Pole 160A Fixed Moulded Case Circuit Breaker

The ABB 1SDA067424R1 XT1N 160 TMD 100-1000 4p F F is a 4-pole, fixed-mount moulded case circuit breaker from the Tmax XT1 series, engineered for reliable power protection in transformer, generator, and installation applications. Featuring a TMD (Thermal-Magnetic trip unit) with an adjustable current range of 100–1000 A and a robust fixed mounting configuration, the XT1N 160 TMD 100-1000 4p F F delivers dependable overcurrent and short-circuit protection in demanding industrial environments. With compact dimensions of 101.6 mm × 130 mm × 70 mm and a weight of just 1.4 kg, it is well-suited for space-constrained control panels and distribution boards.

Technical Specifications

Certifications & Standards

• CE: Conformité Européenne — meets EU safety, health, and environmental requirements
• RoHS: EU Directive 2011/65/EU — restriction of hazardous substances in electrical equipment
• REACH: EU Regulation on Registration, Evaluation, Authorisation and Restriction of Chemicals
• Amendment 2015/863: EU RoHS amendment restricting additional hazardous substances
• IEC 60947-2: International standard for low-voltage circuit breakers — performance and testing requirements
• EN 45555: General methods for the assessment of the ability to recycle, reuse, and recover electrical/electronic equipment
• UL 2799: Standard for electrical systems performance of zero-emission vehicles (component-level listing)
• ATEX: Certified for use in potentially explosive atmospheres (EU Directive 2014/34/EU)
• VDE: Verified by Germany's Association for Electrical, Electronic & Information Technologies
• WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive 2012/19/EU

Applications & Use Cases

• Transformer secondary circuit protection in industrial and commercial power distribution panels
• Generator output protection and automatic isolation during fault conditions
• Installation protection for industrial machinery, motor control centres, and switchgear assemblies
• Main or branch circuit protection in control panels requiring IEC 60947-2 compliant devices
• Applications requiring ATEX-rated components in hazardous or explosive-atmosphere zones
