ABB 1SDA067423R1 XT1N 160 TMD 80-800 4p F F 4-Pole 80A Fixed Moulded Case Circuit Breaker

The ABB XT1N 160 TMD 80-800 4p F F (SKU: 1SDA067423R1) is a 4-pole, 80 A fixed-mount power circuit-breaker from the Tmax XT1 series, engineered for reliable overload and short-circuit protection of transformers, generators, and distribution installations. Featuring a TMD (Thermal-Magnetic Device) trip unit with an adjustable current range of 80–800 A, this compact MCCB delivers robust performance in demanding industrial environments. Its fixed execution and compact footprint — 101.6 mm × 130 mm × 70 mm — make it ideal for space-constrained control panels and switchboards.

Technical Specifications

Certifications & Standards

• IEC 60947-2: International standard for low-voltage circuit-breakers — defines performance, safety, and testing requirements for industrial MCCBs
• CE: Confirms compliance with applicable European Union safety, health, and environmental protection directives
• VDE: German electrotechnical institute certification verifying compliance with VDE and DIN standards
• ATEX: Certified for use in explosive atmospheres per EU Directive 2014/34/EU
• RoHS: Compliant with the Restriction of Hazardous Substances Directive — restricts use of specified hazardous materials in electrical equipment
• REACH: Compliant with EU REACH regulation (EC No 1907/2006) regarding registration, evaluation, and authorisation of chemical substances
• EN 45555: General methods for the assessment of the ability to recover resources from electrical and electronic equipment
• UL 2799: Standard for electrical energy storage systems — affirms product-level safety for integrated applications
• WEEE: Registered under the Waste Electrical and Electronic Equipment Directive for responsible end-of-life disposal and recycling

Applications & Use Cases

• Transformer protection: Guards LV transformer secondaries against overload and downstream fault currents in industrial and commercial substations
• Generator protection: Protects generator output feeders in standby and prime-power installations where robust breaking capacity is critical
• Distribution board protection: Acts as a main or branch incomer in MCC panels, distribution boards, and switchgear assemblies
• Industrial machinery: Provides motor feeder and equipment circuit protection in manufacturing, process, and utilities environments
• ATEX / hazardous areas: Suitable for installations in potentially explosive atmospheres when correctly installed per ATEX zoning requirements
