ABB 1SDA067422R1 XT1N 160 TMD 63-630 4p F F 4-Pole 630A Fixed Moulded Case Circuit Breaker

The ABB 1SDA067422R1 XT1N 160 TMD 63-630 4p F F is a 4-pole fixed-mount moulded case circuit breaker from the Tmax XT1 series, designed for transformer, generator, and installation protection in industrial power distribution systems. Featuring a wide adjustable thermal-magnetic trip unit covering 63–630 A, this breaker delivers reliable overcurrent and short-circuit protection in a compact 101.6 × 130 × 70 mm footprint. Weighing just 1.4 kg, the XT1N 160 TMD 63-630 4p F F is engineered for demanding control panel and switchboard applications where space and performance are equally critical.

Technical Specifications

Certifications & Standards

• CE: Conforms to applicable European Union directives for the CE marking
• RoHS: Compliant with EU Directive 2011/65/EU (Restriction of Hazardous Substances)
• REACH: Compliant with EU REACH regulation on chemical substances
• EU Directive 2011/65/EU & Amendment 2015/863: Full compliance with the updated RoHS directive including Annex II substances
• IEC 60947-2: Meets international standard for low-voltage switchgear — circuit breakers
• EN 45555: Compliant with general methods for the assessment of the ability of energy-related products to be repaired, reused, and recycled
• UL 2799: Listed under UL standard for electrical energy storage systems (supply chain compliance)
• ATEX: Suitable for use in potentially explosive atmospheres per ATEX directive
• VDE: Certified by VDE (Verband der Elektrotechnik), the German electrical engineering association
• WEEE: Registered for proper end-of-life electrical and electronic equipment disposal under EU WEEE Directive
