ABB 1SAM360000R1003 MO132-0.4 0.4A 3P 100kA Motor Protection Circuit-Breaker

The ABB MO132-0.4 (SKU: 1SAM360000R1003) is a 3-pole magnetic-only motor protection circuit-breaker rated at 0.4 A with an exceptional breaking capacity of 100 kA at 400 V AC. Designed for the MO132 series, this compact 45 mm wide device provides reliable short-circuit protection for low-current motor applications in industrial control panels and automation systems. Its magnetic-only trip mechanism ensures instantaneous protection without thermal delay, making it ideal for applications where external overload protection is already provided.

Technical Specifications

Certifications & Standards

• CE: Conformité Européenne — meets EU safety, health, and environmental requirements
• UKCA: UK Conformity Assessed — approved for Great Britain market
• EAC: Eurasian Conformity — certified for Eurasian Economic Union countries
• DNV: Det Norske Veritas — approved for marine and offshore applications
• LR: Lloyd's Register — marine type approval
• RINA: Registro Italiano Navale — Italian naval register approval
• RMRS: Russian Maritime Register of Shipping — marine certification
• UL: Underwriters Laboratories — North American safety certification
• KC: Korea Certification — certified for the South Korean market
• CSA: Canadian Standards Association — certified for Canadian market
• CCC: China Compulsory Certification — certified for the Chinese market
• IEC 60947-1 / EN 60947-1: Low-voltage switchgear and controlgear — general rules
• IEC/EN 60947-2: Low-voltage switchgear — circuit-breakers
• IEC/EN 60947-4: Low-voltage switchgear — contactors and motor-starters
• IEC 60715: Dimensions of low-voltage switchgear — standardised mounting on rails
• IEC 60335-2: Household and similar electrical appliances — safety
• IEC 60068-2: Environmental testing standard
• EN 45555: General methods for the assessment of the energy efficiency of networked products
• UL 2799: Electrical Waste Recycling — zero-landfill validation
• REACH: Registration, Evaluation, Authorisation and Restriction of Chemicals compliance
• RoHS: Restriction of Hazardous Substances — compliant, environmentally responsible
• WEEE: Waste Electrical and Electronic Equipment — proper disposal and recycling compliance

Applications & Use Cases

• Short-circuit protection for small motors in industrial automation and control panels
• Motor branch circuit protection in manufacturing and process industries
• Marine and offshore electrical installations (DNV, LR, RINA, RMRS approved)
• Panel boards and motor control centres (MCCs) requiring compact 45 mm DIN rail mounting
• Applications with separate overload protection where magnetic-only operation is required
• Global installations requiring multi-market certification (UL, CSA, CCC, EAC, KC)
