ABB 1SAM350000R1006 MS132-1.6 1.0-1.6A 3P 100kA 400VAC Motor Protection Circuit Breaker

The ABB MS132-1.6 (SKU: 1SAM350000R1006) is a 3-pole manual motor starter and motor protection circuit-breaker rated for 1.0–1.6 A at 400 VAC, delivering an exceptional breaking capacity of 100 kA at 400 VAC. Part of the MS132 series, the MS132-1.6 provides reliable thermal and magnetic protection for small motors in industrial control panels, combining compact 45 mm width with robust performance across demanding environments.

Technical Specifications

Certifications & Standards

• CE: Conforms to European Union directives for electrical equipment
• UKCA: UK Conformity Assessed marking for the Great Britain market
• UL: Listed under UL508 for industrial control equipment
• CSA: Canadian Standards Association approval
• ATEX: Approved for use in explosive atmospheres (EU Directive 2014/34/EU)
• IECEx: International certification for equipment used in explosive atmospheres
• CCC: China Compulsory Certificate for the Chinese market
• EAC: Eurasian Conformity mark for the EAEU market
• KC: Korea Certification mark
• LR: Lloyd's Register type approval
• RINA: Registro Italiano Navale marine approval
• RMRS: Russian Maritime Register of Shipping approval
• IEC 60947-1: General rules for low-voltage switchgear and controlgear
• EN 60947-1 / EN60947-4: European harmonised standards for low-voltage switchgear
• IEC/EN 60947: Low-voltage switchgear and controlgear family of standards
• EN45555-80: Generic parameters for the assessment of the ability to repair, reuse, and recycle electrical and electronic products
• IEC 60715: Dimensions of low-voltage switchgear and controlgear — standardised mounting on DIN rails
• IEC 60068-2: Environmental testing — climatic and mechanical durability tests
• REACH: Compliant with EU chemicals regulation (EC) No 1907/2006
• RoHS: Restriction of Hazardous Substances Directive compliant
• WEEE: Waste Electrical and Electronic Equipment Directive compliant

Applications & Use Cases

• Direct-on-line motor starting and protection for small three-phase motors (1.0–1.6 A range)
• Machine tool control panels requiring compact 45 mm DIN-rail mounted protection
• Pump and fan motor protection in HVAC and building automation systems
• Conveyor and material-handling equipment motor circuits
• Hazardous area installations (ATEX / IECEx certified environments)
• Marine and offshore control panels (LR, RINA, RMRS approved)
• Industrial automation and process control cabinets worldwide
