- Part number
- 6GT2821-5AC40
- Model no
- RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30.
Siemens has announced the end of 6GT2821-5AC40
Once production ends, supply depends on remaining stock.
No replacement announced yet. Tell us the application and we will propose an alternative.
Siemens 6GT2821-5AC40 SIMATIC RF200 RF250R ASCII RS232 13.56MHz IP65 RFID Reader
SIMATIC RF200 RF250R ASCII RFID reader, RS232 scan-mode, external antenna required, 13.56MHz, IP65.
Description
About the RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30.
About the RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30.
The Siemens 6GT2821-5AC40 is a SIMATIC RF200 RF250R ASCII RFID reader with an RS232 interface running in ASCII/scan mode and no built-in antenna, requiring a separate ANT-series antenna. Housed in a 50 x 50 x 30 mm IP65 enclosure, it reads ISO 15693 transponders at 13.56 MHz and connects directly to a PC or control system.
Certifications & Standards
- EPD
Selection Notes
This variant combines the RF250R's split antenna design (M8, 4-pin antenna port, ANT-series antenna purchased separately) with an RS232 ASCII/scan-mode interface, so it connects directly to a PC or scanner input instead of a SIMATIC communication module. The 30 m maximum wire length is much shorter than the RS422 version's 1000 m, which puts this reader close to the connected PC. Choose it over the RS422 version when the endpoint is a PC or third-party scanner rather than a SIMATIC module, and keep the RS422 version for longer cable runs back to a communication module.
Applications
Used where the antenna must be positioned apart from the reader body and the read data needs to reach a nearby PC or terminal directly, such as manual scan stations or benchtop read/write setups.
Specification
Full specification
General 3
| product type designation | RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. |
|---|---|
| product brand name | SIMATIC RF |
| suitability for operation | ISO 15693 transponder (MDS Dxxx), for connecting to PC and control systems (incl. Scan Mode) |
Radio frequencies 4
| operating frequency / rated value | 13.56 MHz |
|---|---|
| protocol / with radio transmission | ISO 15693, ISO 18000-3 |
| transfer rate / with radio transmission / maximum | 26.5 kbit/s |
| product feature / multitag-capable | No |
Electrical data 3
| transfer rate / at the point-to-point connection / serial / maximum | 115.2 kbit/s |
|---|---|
| transmission time / for user data: for write access / per byte / typical | 1.2 ms |
| transmission time / for user data: for read access / per byte / typical | 1.2 ms |
Show all 59 specifications ↓ Show less ↑49 more values in Identification, Interfaces, Mechanical data, Supply voltage, current consumption, power loss, Ambient conditions, Design, dimensions and weights, Product features, product functions, product components / general, Standards, specifications, approvals, Standards, specifications, approvals / Environmental Product Declaration, Accessories, Logistics.
Identification 8
| Part number | 6GT2821-5AC40 |
|---|---|
| Type designation | RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Phase-out announced by the manufacturer |
| EAN | 4034106024574 |
Interfaces 4
| number of external antennas | 1 |
|---|---|
| standard for interfaces / for communication | RS232 |
| type of electrical connection: for external antenna(s) | M8, 4-pin |
| type of electrical connection: for communications interface | M12, 8-pin |
Mechanical data 4
| material | PA6.6 |
|---|---|
| color | anthracite |
| tightening torque / of the screw for securing the equipment / maximum | 1.5 N·m |
| mounting distance / relating to metal surfaces / recommended / minimum | 0 mm |
Supply voltage, current consumption, power loss 3
| supply voltage / at DC: rated value | 24 V |
|---|---|
| supply voltage / at DC: ● | 20.4 ... 28.8 V |
| consumed current / at DC: at 24 V / typical | 0.05 A |
Ambient conditions 7
| ambient temperature: during operation | -20 ... +70 °C |
|---|---|
| ambient temperature: during storage | -25 ... +80 °C |
| ambient temperature: during transport | -25 ... +80 °C |
| protection class IP | IP65 |
| shock resistance | EN 60721-3-7 Class 7 M2 |
| shock acceleration | 500 m/s2 |
| vibrational acceleration | 200 m/s2 |
Design, dimensions and weights 5
| width | 50 mm |
|---|---|
| height | 30 mm |
| depth | 50 mm |
| fastening method | 2 x M5 screws |
| wire length: with RS 232 interface / maximum | 30 m |
Product features, product functions, product components / general 2
| display version | 3-color LED |
|---|---|
| product feature / silicon-free | Yes |
Standards, specifications, approvals 3
| certificate of suitability | Radio according to R&TTE guidelines EN300 330 and EN 301489, FCC, cULus |
|---|---|
| certificate of suitability: IECEx | No |
| MTBF | 430 a |
Standards, specifications, approvals / Environmental Product Declaration 5
| Environmental Product Declaration | Yes |
|---|---|
| global warming potential [CO2 eq]: total | 50.4 kg |
| global warming potential [CO2 eq]: during manufacturing | 10.7 kg |
| global warming potential [CO2 eq]: during operation | 39.4 kg |
| global warming potential [CO2 eq]: after end of life | 0.3 kg |
Accessories 1
| accessories | Various antennas are available |
|---|
Logistics 7
| Net weight | 0.06 kg |
|---|---|
| Package dimensions | 24 × 90 × 62 mm |
| Country of origin | DE |
| Shipping weight | 0.56 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 01 Nov 2026
Documents
Documents for 6GT2821-5AC40
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- Environmental Product Declaration
Quick answers
Questions about the RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30.
What is the rated current of RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30.?
The rated current of RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. is 0.05 A.
Which supply voltage is RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. rated for?
The rated operational voltage of RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. is 24 V AC.
What is the HS code of RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. for customs?
The tariff (HS) code on file for RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. is 84719000.
What is the EAN of RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30.?
The EAN (GTIN) of RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. is 4034106024574.
Where does RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. ship from, and how fast?
RF250R reader ASCII - - spare part - - SIMATIC RF200 reader RF250R with RS232 interface (ASCII/scan mode) without antenna IP65, -25 to +70 °C, 50x 50x 30 mm, can be operated with: ANT 1, 3, 3 NO, 8, 12, 18, 30. ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
