- Part number
- 6GT2821-4AC40
- Model no
- RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna.
Siemens has announced the end of 6GT2821-4AC40
Once production ends, supply depends on remaining stock.
No replacement announced yet. Tell us the application and we will propose an alternative.
Siemens 6GT2821-4AC40 SIMATIC RF200 RF240R ASCII RS232 13.56MHz IP67 RFID Reader
SIMATIC RF200 RF240R ASCII RFID reader, RS232 scan-mode interface, 13.56MHz ISO 15693, IP67.
Description
About the RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna.
About the RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna.
The Siemens 6GT2821-4AC40 is a SIMATIC RF200 RF240R ASCII RFID reader with an RS232 interface running in ASCII/scan mode, so it connects directly to a PC or control system without a SIMATIC communication module. Built into a 50 x 50 x 30 mm housing with an integrated antenna, it reads ISO 15693 transponders at 13.56 MHz and carries an IP67 rating for -20 to +70°C operation.
Certifications & Standards
- EPD
Selection Notes
The RS232 ASCII/scan-mode interface is the key difference from the RS422 version of this reader: it lets the reader output tag data as plain text straight to a PC or scanner input, skipping the SIMATIC communication module the RS422 variant needs. The 30 m maximum wire length is far shorter than the RS422 version's 1000 m, so this reader belongs close to the connected PC, not at the far end of a machine. Choose the RS422 variant instead when the reader has to sit on a long cable run back to a SIMATIC communication module; choose this ASCII variant when a PC or third-party scanner input is the endpoint.
Applications
Used where tag data needs to reach a nearby PC or terminal directly, such as manual read stations, packing benches, or scan-mode kiosks, without routing through a SIMATIC communication module.
Specification
Full specification
General 3
| product type designation | RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. |
|---|---|
| product brand name | SIMATIC RF |
| suitability for operation | ISO 15693 transponder (MDS Dxxx), for connecting to PC and control systems (incl. Scan Mode) |
Radio frequencies 4
| operating frequency / rated value | 13.56 MHz |
|---|---|
| protocol / with radio transmission | ISO 15693, ISO 18000-3 |
| transfer rate / with radio transmission / maximum | 26.5 kbit/s |
| product feature / multitag-capable | No |
Electrical data 3
| transfer rate / at the point-to-point connection / serial / maximum | 115.2 kbit/s |
|---|---|
| transmission time / for user data: for write access / per byte / typical | 1.2 ms |
| transmission time / for user data: for read access / per byte / typical | 1.2 ms |
Show all 59 specifications ↓ Show less ↑49 more values in Identification, Interfaces, Mechanical data, Supply voltage, current consumption, power loss, Ambient conditions, Design, dimensions and weights, Product features, product functions, product components / general, Standards, specifications, approvals, Standards, specifications, approvals / Environmental Product Declaration, General Product Approval, Logistics.
Identification 10
| Part number | 6GT2821-4AC40 |
|---|---|
| Type designation | RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Phase-out announced by the manufacturer |
| EAN | 4034106024543 |
| ETIM class | EC002998 |
| eCl@ss | 27280401 |
Interfaces 2
| standard for interfaces / for communication | RS232 |
|---|---|
| type of electrical connection | M12, 8-pin |
Mechanical data 4
| material | PA6.6 |
|---|---|
| color | anthracite |
| tightening torque / of the screw for securing the equipment / maximum | 1.5 N·m |
| mounting distance / relating to metal surfaces / recommended / minimum | 0 mm |
Supply voltage, current consumption, power loss 3
| supply voltage / at DC: rated value | 24 V |
|---|---|
| supply voltage / at DC: ● | 20.4 ... 28.8 V |
| consumed current / at DC: at 24 V / typical | 0.05 A |
Ambient conditions 7
| ambient temperature: during operation | -20 ... +70 °C |
|---|---|
| ambient temperature: during storage | -25 ... +80 °C |
| ambient temperature: during transport | -25 ... +80 °C |
| protection class IP | IP67 |
| shock resistance | EN 60721-3-7 Class 7 M2 |
| shock acceleration | 500 m/s2 |
| vibrational acceleration | 200 m/s2 |
Design, dimensions and weights 5
| width | 50 mm |
|---|---|
| height | 30 mm |
| depth | 50 mm |
| fastening method | 2 x M5 screws |
| wire length: with RS 232 interface / maximum | 30 m |
Product features, product functions, product components / general 2
| display version | 3-color LED |
|---|---|
| product feature / silicon-free | Yes |
Standards, specifications, approvals 3
| certificate of suitability | Radio according to R&TTE guidelines EN300 330 and EN 301489, FCC, cULus |
|---|---|
| certificate of suitability: IECEx | No |
| MTBF | 430 a |
Standards, specifications, approvals / Environmental Product Declaration 5
| Environmental Product Declaration | Yes |
|---|---|
| global warming potential [CO2 eq]: total | 50.4 kg |
| global warming potential [CO2 eq]: during manufacturing | 10.7 kg |
| global warming potential [CO2 eq]: during operation | 39.4 kg |
| global warming potential [CO2 eq]: after end of life | 0.3 kg |
General Product Approval 1
| China RoHS Manufacturer Declara- | tion |
|---|
Logistics 7
| Net weight | 0.06 kg |
|---|---|
| Package dimensions | 75 × 75 × 41 mm |
| Country of origin | DE |
| Shipping weight | 0.56 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 01 Nov 2026
Documents
Documents for 6GT2821-4AC40
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- Environmental Product Declaration
Quick answers
Questions about the RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna.
What is the rated current of RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna.?
The rated current of RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. is 0.05 A.
Which supply voltage is RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. rated for?
The rated operational voltage of RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. is 24 V AC.
What is the HS code of RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. for customs?
The tariff (HS) code on file for RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. is 84719000.
What is the EAN of RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna.?
The EAN (GTIN) of RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. is 4034106024543.
Where does RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. ship from, and how fast?
RF240R reader ASCII SIMATIC RF200 Reader RF240R; RS-232 interface (ASCII/scan mode); IP67, -25 to +70 °C; 50x 50x 30 mm; with integrated antenna. ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
