- Part number
- 6GT2600-0AF00
- Model no
- MDS D127 transponder transponder MDS D127 for RF200/RF300 ISO on-metal transponder M6 ISO 15693 chip type, NXP ICODE SLI, 112 byte user memory; 6x 6 mm (DxH); minimum order quantity 10 units
Siemens 6GT2600-0AF00 SIMATIC RF300 MDS D127 ISO 15693 M6 On-Metal RFID Transponder
Siemens MDS D127 on-metal ISO 15693 transponder, M6 size, 112-byte EEPROM, IP68.
Description
About the MDS D127 transponder transponder MDS D127 for RF200/RF300 ISO on-metal transponder M6 ISO 15693 chip type, NXP ICODE SLI, 112 byte user memory; 6x 6 mm (DxH); minimum order quantity 10 units
About the MDS D127 transponder transponder MDS D127 for RF200/RF300 ISO on-metal transponder M6 ISO 15693 chip type, NXP ICODE SLI, 112 byte user memory; 6x 6 mm (DxH); minimum order quantity 10 units
The Siemens 6GT2600-0AF00 is an MDS D127 on-metal transponder for the RF200 and RF300 read/write systems, sized as an M6 disc (6 x 5.8 mm) with ISO 15693 operation at 13.56 MHz and 112 bytes of EEPROM user memory. It can be screwed or glued directly onto a steel fixture with zero recommended clearance, and it carries an IP68/IPx9K rating for washdown environments.
Certifications & Standards
- EPD
Selection Notes
The 0 mm minimum mounting distance is what defines this variant: unlike the standard button transponders in the MDS D1xx line, which need a spacer to clear detuning from a metal fixture, the 6GT2600-0AF00 mounts flush on steel because its on-metal construction already compensates for the eddy-current losses. The compact 6 mm disc and M6 screw or adhesive fixing suit tooling and fixture tracking where panel space is tight and the tag sits permanently on a metal carrier. For non-metal or free-standing mounts, the standard-body transponder in this series is the simpler and lower-cost choice.
Specification
Full specification
General 3
| product type designation | MDS D127 transponder transponder MDS D127 for RF200/RF300 ISO on-metal transponder M6 ISO 15693 chip type, NXP ICODE SLI, 112 byte user memory; 6x 6 mm (DxH); minimum order quantity 10 units |
|---|---|
| suitability for operation | RF200, RF300 |
| product brand name | SIMATIC RF |
Radio frequencies 4
| operating frequency / rated value | 13.56 MHz |
|---|---|
| protocol / with radio transmission | ISO 15693 |
| transfer rate / with radio transmission / maximum | 26.5 kbit/s |
| product feature / multitag-capable | Yes |
Electrical data 1
| product component / backup battery | No |
|---|
Show all 54 specifications ↓ Show less ↑46 more values in Identification, Memory, Mechanical data, Ambient conditions, Product features, product functions, product components / general, Standards, specifications, approvals, Standards, specifications, approvals / Environmental Product Declaration, Logistics.
Identification 10
| Part number | 6GT2600-0AF00 |
|---|---|
| Type designation | MDS D127 transponder transponder MDS D127 for RF200/RF300 ISO on-metal transponder M6 ISO 15693 chip type, NXP ICODE SLI, 112 byte user memory; 6x 6 mm (DxH); minimum order quantity 10 units |
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| EAN | 4047618019709 |
| ETIM class | EC002996 |
| eCl@ss | 27280402 |
Memory 8
| type of memory | EEPROM |
|---|---|
| storage capacity / of the user memory | 112 byte |
| type of memory organization | UID (fixed code) 8 bytes, user memory 112 bytes, configuration memory 8 bytes |
| number of read cycles / at ambient temperature < 40 °C / maximum | 1E+14 |
| number of write cycles / at ambient temperature < 40 °C / maximum | 100000 |
| data retention time / at ambient temperature < 40 °C / not less than | 10 a |
| property of memory | Block-by-block write protection of the user memory |
| type of transponder chip used | NXP I-Code SLI |
Mechanical data 3
| material | PA6 |
|---|---|
| color | black |
| mounting distance / relating to metal surfaces / recommended / minimum | 0 mm |
Ambient conditions 10
| ambient temperature: during read/write access | -25 ... +100 °C |
|---|---|
| ambient temperature: outside the read/write area | -40 ... +125 °C |
| ambient temperature: during storage | -40 ... +125 °C |
| protection class IP | IP68/IPx9K |
| shock resistance | According to DIN EN 60721-3-7 Class 7 M3 |
| shock acceleration | 1000 m/s2 |
| vibrational acceleration design, dimensions and weights | 200 m/s2 |
| height | 5.8 mm |
| diameter | 6 mm |
| fastening method | gluing, screwing |
Product features, product functions, product components / general 1
| product feature: printable | No |
|---|
Standards, specifications, approvals 2
| certificate of suitability: IECEx | No |
|---|---|
| MTBF | 228 a |
Standards, specifications, approvals / Environmental Product Declaration 5
| Environmental Product Declaration | Yes |
|---|---|
| global warming potential [CO2 eq]: total | 0.93 kg |
| global warming potential [CO2 eq]: during manufacturing | 0.88 kg |
| global warming potential [CO2 eq]: during operation | 0.00041 kg |
| global warming potential [CO2 eq]: after end of life | 0.05 kg |
Logistics 7
| Net weight | 1 kg |
|---|---|
| Package dimensions | 6 × 6 × 6 mm |
| Country of origin | Romania |
| Shipping weight | 1.5 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 01 Nov 2026
