Part number
XB6DD221B
Model no
XB6
$23.09 On request Dispatch — · From TürkiyeGet a Quote
Harmony XB6

Schneider Electric XB6DD221B Harmony XB6 Black Rectangular 16 mm 2-Position Stay Put 1NO+1NC Selector Switch

Schneider Electric XB6DD221B Harmony XB6 selector switch, black rectangular, 2-position stay put, 1NO+1NC.

Range of Product
Harmony XB6
Product or Component Type
Complete selector switch
Device short name
XB6
Bezel material
Plastic
Mounting diameter
0.6 in (16 mm)
Sale per indivisible quantity
1
EAN
3389110764574
Description

About the XB6

The Schneider Electric XB6DD221B is a Harmony XB6 complete selector switch with a black rectangular handle on a 16 mm plastic bezel, stay-put operator with 2 positions at 60 degrees, and 1NO+1NC slow-break contacts. It mounts into a 16 mm cut-out for compact mode or source selection in small panels.

Certifications & Standards

  • UL
  • CCC
  • CSA
  • GOST
  • IEC 60947-5-5
  • JIS C8201-5-1
  • IEC 60947-1
  • JIS C 852
  • IEC 60947-5-1
  • CSA C22.2 No 14
  • UL 508
  • JIS C8201-1

Selection Notes

The 2-position stay-put handle holds whichever position it is turned to, suiting a mode-select function such as local/remote or auto/manual, where the 3-position XB6DD235B adds a centre-off state instead. The 1NO+1NC contact pair lets a single switch confirm which position is active and interlock the opposite function. Because the handle has no key, any operator can change position, unlike the key-locked XB6DGC5B.

Specification

Full specification

51 values · Last verified 30 Oct 2026

Main 13

Range of Product Harmony XB6
Product or Component Type Complete selector switch
Device short name XB6
Bezel material Plastic
Mounting diameter 0.6 in (16 mm)
Sale per indivisible quantity 1
Operating position Any position
Shape of signaling unit head Rectangular
Type of operator stay put
Operator profile Black standard handle
Operator position information 2 positions 60°
Contacts type and composition 1 NO + 1 NC
Contact operation Slow-break

Complementary 15

Height 0.7 in (18 mm)
Width 0.9 in (24 mm)
Depth 2.7 in (68 mm)
Terminals description ISO n°1 (13-14)NO
Net Weight 0.046 lb(US) (0.021 kg)
Positive opening With IEC 60947-5-1 appendix K
Mechanical durability 500000 cycles
Connections - terminals Faston connectors 2.8 x 0.5 mm
Contacts material Silver alloy (Ag/Ni)
Short-circuit protection 6 A cartridge fuse gG
[Ui] rated insulation voltage 250 V 3)IEC 60947-1
[Uimp] rated impulse withstand voltage 4 kV IEC 60947-1
[Ie] rated operational current 3 A 120 V, AC-15, B300 IEC 60947-5-1, 1.5 A 240 V, AC-15, B300 IEC 60947-5-1, 0.1 A 250 V, DC-13, R300 IEC 60947-5-1, 0.22 A 125 V, DC-13, R300 IEC 60947-5-1
Electrical durability 1000000 cycles, AC-15 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
Electrical reliability Λ = 10exp(-8) 5 V 1 mA with confidence level of 90 % IEC 60947-5-4

Environment 9

Protective treatment TC
Ambient Air Temperature for Storage -40…158 °F (-40…70 °C)
Ambient Air Temperature for Operation -13…158 °F (-25…70 °C)
Electrical shock protection class Class II conforming to IEC 61140
IP degree of protection IP65 IEC 60529
NEMA degree of protection NEMA 13 UL 50, NEMA 4 UL 50, NEMA 4X UL 50, NEMA 13 CSA C22.2 No 94, NEMA 4 CSA C22.2 No 94, NEMA 4X CSA C22.2 No 94
Standards IEC 60947-5-5, JIS C8201-5-1, IEC 60947-1, JIS C 852, IEC 60947-5-1, CSA C22.2 No 14, UL 508, JIS C8201-1
Product Certifications UL, CCC, CSA, GOST
Shock resistance 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Show all 51 specifications ↓ Show less ↑14 more values in Identification, Contractual warranty, Logistics.

Identification 8

Part number XB6DD221B
Type designation XB6
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 3389110764574

Contractual warranty 1

Warranty (in months) 18

Logistics 5

Country of origin FR
Shipping weight 0.021 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for XB6DD221B

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • UL
  • CSA
  • CCC
  • IEC 60947-5-5
  • JIS C8201-5-1
  • IEC 60947-1
  • JIS C 852
  • IEC 60947-5-1
  • CSA C22.2 No 14
  • UL 508
  • JIS C8201-1
Quick answers

Questions about the XB6

What is the HS code of XB6 for customs?

The tariff (HS) code on file for XB6 is 853650.

What is the EAN of XB6?

The EAN (GTIN) of XB6 is 3389110764574.

Where does XB6 ship from, and how fast?

XB6 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
