Schneider Electric XB6AW3B1B Harmony XB6 Illuminated Green Flush 16 mm Spring Return 1NO Push Button

The Schneider Electric XB6AW3B1B is a Harmony XB6 complete illuminated push button with a green flush round head, 16 mm plastic bezel, spring-return operator, and 1NO slow-break contact, supplied at 12...24 V AC/DC. It mounts into a 16 mm cut-out and connects with Faston screw-clamp-style terminals for compact panel wiring.

Technical Specifications

Certifications & Standards

• CSA
• UL
• CCC
• GOST
• CSA C22.2 No 14
• JIS C 852
• IEC 60947-5-1
• IEC 60947-5-5
• JIS C 4520
• IEC 60947-1

Selection Notes

The spring-return operator pulses the contact only while the button is held, so it suits a momentary start or jog command rather than a maintained state. Green follows IEC 60073 colour-coding for start/on commands, distinguishing it from a red stop button in the same panel. Running on 12...24 V AC/DC with only 15 mA draw, the integral LED shares the same low-voltage control supply as the contact, with no separate lamp transformer needed.
