Schneider Electric XB6AF1B5B Harmony XB6 Illuminated White Flush 16 mm Latching 1NO+1NC Push Button

The Schneider Electric XB6AF1B5B is a Harmony XB6 complete illuminated push button with a white flush round head, 16 mm plastic bezel, latching operator, and 1NO+1NC slow-break contacts, supplied at 12...24 V AC/DC. It mounts into a 16 mm cut-out, suiting compact panels and small machines where space is limited.

Technical Specifications

Certifications & Standards

• UL
• CSA
• GOST
• CCC
• JIS C 852
• EN/IEC 60947-5-5
• EN/IEC 60947-1
• JIS C 4520
• CSA C22.2 No 14
• UL 508
• EN/IEC 60947-5-1

Selection Notes

The latching operator keeps the button pressed-in after actuation until manually released, so it suits a maintained command such as enabling a mode rather than a momentary start pulse. The 1NO+1NC contact pair lets one device drive both a start confirmation and an interlock signal from a single actuation. Running on 12...24 V AC/DC with only 15 mA draw, the integral LED shares the same low-voltage control supply as the contacts, so no separate lamp transformer is needed.
