Schneider Electric XB4BL73415 Harmony XB4 Double-Headed Flush Green I Projecting Red O 1NO+1NC Push Button

% $-28.33
Schneider Electric XB4BL73415 Harmony XB4 double push button green I red O - 1NO+1NC
Schneider Electric XB4BL73415 Harmony XB4 double push button green I red O - 1NO+1NC

Schneider Electric XB4BL73415 Harmony XB4 Double-Headed Flush Green I Projecting Red O 1NO+1NC Push Button

Brand: Schneider Electric
Reference No: XB4BL73415
Catalog No: XB4BL73415
Series: Harmony XB4
Tariff Code (HS): 853650
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$28.33

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric XB4BL73415 is a Harmony XB4 double-headed push button combining a flush green button marked I with a projecting red button marked O, in one metal assembly. It operates on a spring return mechanism, switches 1 NO + 1 NC with positive opening, and installs into a single 22.5 mm panel cut-out with screw-clamp terminals.

Technical Specifications

SKU XB4BL73415
Brand Schneider Electric
Range Harmony XB4
Product Type Double-headed push-button
Bezel Material Chromium plated metal
Mounting Diameter 22.5 mm
Head Shape Rectangular, 1 flush + 1 projecting
Operator Markings Green flush, I (white) - Red projecting, O (white)
Contacts 1 NO + 1 NC, slow-break
Positive Opening With, per IEC 60947-5-1 appendix K
Rated Insulation / Impulse Withstand Voltage 600 V / 6 kV
Conventional Thermal Current (Ith) 10 A
Rated Operational Current (Ie) 3 A at 240 V / 6 A at 120 V, AC-15
Short-circuit Protection 10 A gG cartridge fuse
Contact Material Silver alloy (Ag/Ni)
IP Degree of Protection IP67 / IP69 / IP69K
IK Degree of Protection IK06
Operating Temperature -40...70 C
Net Weight 0.116 kg

Certifications & Standards

  • IEC 60947-5-1
  • UL 508
  • CSA C22.2 No 14
  • DNV
  • BV

Selection Notes

Combining a flush green start button with a projecting red stop button in one 22.5 mm cut-out lets a panel builder fit a start/stop pair without two separate holes, with the projecting STOP head easier to find and hit without looking. Wire the O head to the 1 NC side for a fail-safe stop, with the I head carrying the 1 NO start command; the triple-headed XB4BA711237 and XB4BA731327 in the same range extend this pattern to a third function.

Technical Details

Short Description
Harmony XB4 double push button, flush green I / projecting red O, 1NO+1NC, single cut-out.
Mounting Type
Panel mount, 22.5 mm cut-out
Protection Type
IP69K
Catalog No
XB4BL73415
Delivery Date (Days)
30 days
Model Number
XB4BL
Tariff Code
853650
