Schneider Electric XB4BA21 Harmony XB4 push button black flush - 1NO

Schneider Electric XB4BA21 Harmony XB4 Push Button Metal Flush Black 22 mm Spring Return 1NO Push Button

Name: Schneider Electric XB4BA21 Harmony XB4 Push Button Metal Flush Black 22 mm Spring Return 1NO Push Button
Brand: Schneider Electric
SKU: XB4BA21
Price: 7.83 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Brand: Schneider Electric

Reference No: XB4BA21

Catalog No: XB4BA21

Series: Harmony XB4

Tariff Code (HS): 853650

Stock: 0

Delivery time: 30 business day(s)

Shipping Origin: Türkiye EXW

$7.83

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Schneider Electric XB4BA21 is a Harmony XB4 22 mm modular push button with a black flush metal operator, unmarked. It operates on a spring return mechanism, switches 1 NO contact rated 10 A Ith, and mounts into a standard 22.5 mm panel cut-out with screw-clamp terminals. The sealed metal body is rated up to IP69K for washdown environments.

Technical Specifications

SKU	XB4BA21
Brand	Schneider Electric
Range	Harmony XB4
Product Type	Push-button
Bezel Material	Chromium plated metal
Fixing Collar Material	Zamak
Mounting Diameter	22.5 mm
Operator Type	Spring return
Operator Profile	Black flush, unmarked
Contacts	1 NO, slow-break
Rated Insulation / Impulse Withstand Voltage	600 V / 6 kV
Conventional Thermal Current (Ith)	10 A
Rated Operational Current (Ie)	3 A at 240 V / 6 A at 120 V, AC-15
Short-circuit Protection	10 A gG cartridge fuse
Contact Material	Silver alloy (Ag/Ni)
IP Degree of Protection	IP66 / IP67 / IP69 / IP69K
IK Degree of Protection	IK06
Operating Temperature	-40...70 C
Net Weight	0.08 kg

Certifications & Standards

IEC 60947-5-1
UL 508
CSA C22.2 No 14
DNV
BV

Selection Notes

Unmarked and black, the XB4BA21 is the default general-purpose push button in the XB4 metal range. Specify the marked I/O or arrow-symbol variants in the same range where the panel needs a labelled start, stop or jog function instead of a plain button, or switch to a 1 NC version where the control logic requires a normally-closed contact.

Technical Details

Short Description

Harmony XB4 22 mm push button, black flush metal, unmarked, spring return, 1NO, IP69K.

Mounting Type

Panel mount, 22.5 mm cut-out

Protection Type

IP69K

Catalog No

XB4BA21

Delivery Date (Days)

30 days

Model Number

XB4BA

Tariff Code

853650
