Schneider Electric XA2AJ33 Easy Harmony XA2 Plastic Long Handle Black 22 mm 3-Position 2NO Selector Switch

% $-6.16
Schneider Electric XA2AJ33 Easy Harmony XA2 Selector Switch Long Handle Black 22mm 2NO
Schneider Electric XA2AJ33 Easy Harmony XA2 Selector Switch Long Handle Black 22mm 2NO

Schneider Electric XA2AJ33 Easy Harmony XA2 Plastic Long Handle Black 22 mm 3-Position 2NO Selector Switch

Brand: Schneider Electric
Reference No: XA2AJ33
Catalog No: XA2AJ33
Series: Harmony XA2
Tariff Code (HS): 853650
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$6.16

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric XA2AJ33 is an Easy Harmony XA2 complete selector switch with a black long handle and 3 operating positions spaced 45 degrees apart. It switches 2 NO contacts through slow-break operation and holds each position with a stay-put mechanism, mounting in a 22.5 mm panel cutout sealed to IP65.

Technical Specifications

Reference XA2AJ33
Brand Schneider Electric
Range Easy Harmony XA2
Product Type Complete selector switch
Bezel / Fixing Collar Material Plastic
Mounting Diameter 22.5 mm
Operator Profile Black long handle (white)
Operator Position 3 positions, 45 degrees
Type of Operator Stay put
Contacts Type and Composition 2 NO
Contact Operation Slow-break
Connections - Terminals Screw clamp, <=2 x 1.5 mm2; Faston 6.3 mm
[Ith] Conventional Free Air Thermal Current 10 A
[Ui] Rated Insulation Voltage 600 V
[Uimp] Rated Impulse Withstand Voltage 6 kV
[Ie] Rated Operational Current 3 A at 240 V AC-15; 0.27 A at 250 V DC-13
Dimensions (W x H x D) 30 x 43 x 70 mm
Net Weight 0.055 kg
IP Degree of Protection IP65
IK Degree of Protection IK06
Ambient Temperature (Operation) -25...55 degrees C

Certifications & Standards

  • CCC
  • CE
  • UKCA
  • GB 14048.1
  • IEC 60947-1
  • GB 14048.5
  • IEC 60947-5-1

Selection Notes

With 3 positions and stay-put operation, this long-handle switch latches 2 NO contacts across three distinct states (for example off / manual / auto), each held without needing the operator to keep the handle turned. The 2 NO contact composition supports a PLC or control circuit reading two separate confirmation signals from the same switch body. For only two switched states, choose the XA2AJ21 or XA2AJ25 2-position variants instead.

Technical Details

Short Description
Easy Harmony XA2 selector switch, long handle, 22mm, 3-position, stay put, 2NO, IP65.
Mounting Type
22.5 mm panel cutout
Protection Type
IP65, IK06
Catalog No
XA2AJ33
Delivery Date (Days)
30 days
Model Number
Easy Harmony XA2
Tariff Code
853650
