Schneider Electric XA2AH051 Easy Harmony XA2 Push Button Plastic Flush Yellow 22 mm Push-Push 1NO Push Button

% $-4.54
Schneider Electric XA2AH051 Easy Harmony XA2 Push Button Yellow Flush 22mm 1NO
Schneider Electric XA2AH051 Easy Harmony XA2 Push Button Yellow Flush 22mm 1NO

Schneider Electric XA2AH051 Easy Harmony XA2 Push Button Plastic Flush Yellow 22 mm Push-Push 1NO Push Button

Brand: Schneider Electric
Reference No: XA2AH051
Catalog No: XA2AH051
Series: Harmony XA2
Tariff Code (HS): 853650
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$4.54

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric XA2AH051 is an Easy Harmony XA2 complete push button with a yellow, unmarked, flush head and a push-push (self-lock) operating mechanism. It switches 1 NO contact through slow-break operation and mounts in a 22.5 mm panel cutout, sealed to IP65.

Technical Specifications

Reference XA2AH051
Brand Schneider Electric
Range Easy Harmony XA2
Product Type Complete push-button
Bezel / Fixing Collar Material Plastic
Mounting Diameter 22.5 mm
Operator Profile Yellow flush, unmarked
Type of Operator Push-push (self-lock)
Contacts Type and Composition 1 NO
Contact Operation Slow-break
Connections - Terminals Screw clamp, <=2 x 1.5 mm2; Faston 6.3 mm
[Ith] Conventional Free Air Thermal Current 10 A
[Ui] Rated Insulation Voltage 600 V
[Uimp] Rated Impulse Withstand Voltage 6 kV
[Ie] Rated Operational Current 3 A at 240 V AC-15; 0.27 A at 250 V DC-13
Dimensions (W x H x D) 30 x 43 x 55 mm
Net Weight 0.035 kg
IP Degree of Protection IP65
IK Degree of Protection IK03
Ambient Temperature (Operation) -25...55 degrees C

Certifications & Standards

  • CCC
  • CE
  • UKCA
  • GB 14048.1
  • IEC 60947-1
  • GB 14048.5
  • IEC 60947-5-1

Selection Notes

Push-push (self-lock) operation latches the 1 NO contact closed on the first press and releases it on the second, giving a maintained state without a key. Yellow follows the IEC 60204-1 convention for an abnormal-condition or caution command, distinguishing it from the green (normal start) and red (stop) caps in the same XA2A body style. Pick the matching XA2AH042 (red, 1NC) if the circuit needs a stop function instead.

Technical Details

Short Description
Easy Harmony XA2 push button, 22mm, yellow flush, push-push self-lock, 1NO, IP65.
Mounting Type
22.5 mm panel cutout
Protection Type
IP65, IK03
Catalog No
XA2AH051
Delivery Date (Days)
30 days
Model Number
Easy Harmony XA2
Tariff Code
853650
