Schneider Electric VW3M8A11 Lexium 16 BCH16 Plastic Encoder Connection Kit Servo Drive Accessory

% $-8.06
Schneider Electric VW3M8A11 Easy Lexium 16 BCH16 Encoder Connection Kit
Schneider Electric VW3M8A11 Easy Lexium 16 BCH16 Encoder Connection Kit

Schneider Electric VW3M8A11 Lexium 16 BCH16 Plastic Encoder Connection Kit Servo Drive Accessory

Brand: Schneider Electric
Reference No: VW3M8A11
Catalog No: VW3M8A11
Series: Easy Lexium 16
Tariff Code (HS): 853690
Poles: 3P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$8.06

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric VW3M8A11 is a plastic encoder connection kit for the Easy Lexium 16 range, used to create encoder cordsets for BCH16 servo motors. The kit comprises 1 connector and 9 wiring pins and fits the BCH16 0.1 kW, 0.2 kW, 0.4 kW and 0.75 kW motors running at 3000 rpm.

Technical Specifications

Reference VW3M8A11
Brand Schneider Electric
Range of Product Easy Lexium 16
Accessory / Separate Part Category Spare part
Product or Component Type Connection kit
Device Application For creating encoder cordsets
Kit Composition 1 connector | 9 wiring pins
Product Compatibility Servo motor BCH16 0.1 kW, 3000 rpm, 40 mm | Servo motor BCH16 0.2 kW, 3000 rpm, 60 mm | Servo motor BCH16 0.4 kW, 3000 rpm, 60 mm | Servo motor BCH16 0.75 kW, 3000 rpm, 80 mm
Number of Units in Package 1 1
Number of Units in Package 2 50

Selection Notes

The VW3M8A11 is the plastic-body connection kit for field-building BCH16 encoder cordsets, supplying the connector and 9 wiring pins needed to terminate the cable. One kit covers all four BCH16 frame/power combinations — 0.1 kW, 0.2 kW, 0.4 kW and 0.75 kW, all at 3000 rpm — so the same reference serves every BCH16 motor regardless of frame size.

Technical Details

Short Description
Plastic encoder connection kit, Easy Lexium 16, for BCH16 servo motors, 1 connector + 9 pins.
Catalog No
VW3M8A11
Number of Poles
3P
Delivery Date (Days)
30 days
Model Number
BCH16
Tariff Code
853690
