Schneider Electric VW3M5A12 Lexium 16 BCH16 Plastic Connection Kit Brake Servo Drive Accessory

% $-4.96
Schneider Electric VW3M5A12 Lexium 16 BCH16 plastic brake connection kit
Schneider Electric VW3M5A12 Lexium 16 BCH16 plastic brake connection kit

Schneider Electric VW3M5A12 Lexium 16 BCH16 Plastic Connection Kit Brake Servo Drive Accessory

Brand: Schneider Electric
Reference No: VW3M5A12
Catalog No: VW3M5A12
Series: Lexium 16D
Tariff Code (HS): 853690
Poles: 3P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$4.96

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric VW3M5A12 is a plastic connection kit for building the holding-brake cable of a BCH16 servo motor in the Lexium 16D range. It comprises one connector and two wiring pins, so the brake cable is assembled on site rather than purchased preassembled. It fits the 0.1-0.75 kW BCH16 motor frames.

Technical Specifications

Reference VW3M5A12
Brand Schneider Electric
Range Compatibility Lexium 16D
Product Type Connection kit (spare part)
Device Application Building the holding-brake cable
Kit Composition 1 connector, 2 wiring pins
Compatible Motors Servo motor BCH16, 40/60/80 mm frame, 0.1-0.75 kW
Units per Package (inner) 1
Units per Package (outer) 50

Selection Notes

The VW3M5A12 is the brake-only counterpart to the VW3M5A11 power kit, supplying one connector and two wiring pins sized for the brake coil circuit, and is used together with the power kit on brake-equipped BCH16 motors rather than as a substitute for it. Choose the preassembled VW3M5A12R05 cable instead when a standard 5 m brake cable is sufficient and on-site crimping is not wanted.

Technical Details

Short Description
Lexium 16 BCH16 plastic brake connection kit, 1 connector, 2 wiring pins, 50/pack.
Catalog No
VW3M5A12
Number of Poles
3P
Delivery Date (Days)
30 days
Model Number
Lexium 16 BCH16
Tariff Code
853690
