Schneider Electric VW3M4A12 Easy Lexium 16 CN1 Adapter Tool Set 24 V PTI Cable Servo Drive Accessory

% $-277.68
Schneider Electric VW3M4A12 Easy Lexium 16 CN1 Adapter Tool Set
Schneider Electric VW3M4A12 Easy Lexium 16 CN1 Adapter Tool Set

Schneider Electric VW3M4A12 Easy Lexium 16 CN1 Adapter Tool Set 24 V PTI Cable Servo Drive Accessory

Brand: Schneider Electric
Reference No: VW3M4A12
Catalog No: VW3M4A12
Series: Easy Lexium 16
Tariff Code (HS): 853690
Poles: 3P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$277.68

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric VW3M4A12 is a CN1 adapter tool set for the Easy Lexium 16 range, connecting control wiring to an LXM16D servo drive through a 24 V PTI interface. The kit includes one cordset and one interface module, giving a quick-connect adapter in place of wiring the CN1 SCSI-26 connector pin by pin.

Technical Specifications

Reference VW3M4A12
Brand Schneider Electric
Range of Product Easy Lexium 16
Product or Component Type Adaptor tool set
Accessory / Separate Part Category Spare part
Device Application Connection of control with 24 V PTI
Kit Composition 1 cordset; 1 interface module
Product Compatibility Motion servo drive LXM16D, 0.1-1.5 kW, 200...230 V single phase
Number of Units in Package 1 1
Number of Units in Package 2 2

Selection Notes

The VW3M4A12 fits the same LXM16D drive range as the VW3M4A11 but trades the bare SCSI-26 connector kit for a ready-made 24 V PTI adapter, so it suits commissioning or bench setups where a quick-connect control interface is more useful than a field-terminated cordset. One cordset plus one interface module covers the full 0.1-1.5 kW LXM16D power range.

Applications

Used for quick control-wiring connection to an LXM16D servo drive during commissioning or bench testing, in place of terminating the CN1 SCSI-26 connector by hand.

Technical Details

Short Description
CN1 adapter tool set with 24 V PTI cable for Easy Lexium 16 LXM16D servo drives.
Catalog No
VW3M4A12
Number of Poles
3P
Delivery Date (Days)
30 days
Model Number
LXM16D
Tariff Code
853690
