The TPCDIO13 is a Schneider Electric TransferPacT plug-in I/O module that accepts a constant 230 V AC fire-protection signal at 50/60 Hz. It drives the transfer switch to the off position while the fire alarm system holds the signal energized, matching sites whose fire-protection loop runs at mains voltage rather than 24 V DC.
| Range of product | TransferPacT |
|---|---|
| Product or component type | I/O module |
| Device application | Signalling |
| Auxiliary contact composition | 1 NO |
|---|---|
| Signalling function | Fire protection (transfer to off position) |
| Auxiliary connection terminal | Screw clamp terminal 0.05…2.6 mm² |
| Mounting mode | Plug-in |
| Mounting position | Left-bottom |
| Maximum input current | 10 mA 230 V AC +/- 20 % |
| [Ui] rated insulation voltage | 300 V AC |
| Tightening torque | 0.6 N.m +/- 0.1 N.m |
| Height | 56.5 mm |
| Width | 20 mm |
| Depth | 69 mm |
| Net weight | 40 g |
| Accessory / separate part category | Signalling accessory |
| IP degree of protection | IP20 |
|---|---|
| Pollution degree | 3 |
| Part number | TPCDIO13 |
|---|---|
| Brand | Schneider Electric |
| Condition | New, factory sealed |
| Source | Schneider Electric and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Active, in production |
| Warranty (in months) | 18 |
|---|
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.400 cm |
| Package 1 Width | 10.500 cm |
| Package 1 Length | 10.700 cm |
| Package 1 Weight | 86.000 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 20 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 1.996 kg |
| Shipping weight | 0.04 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 30 Oct 2026
No documents are on file for this part yet.
Ask us for the datasheetThe rated operational voltage of TPCDIO13 is 230 V AC.
The tariff (HS) code on file for TPCDIO13 is 853890.
TPCDIO13 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
