Part number
TA16D3L1254TPE
$887.40 On request Dispatch — · From TürkiyeGet a Quote
TransferPacT

Schneider Electric TA16D3L1254TPE TransferPacT 3P 125 A LCD 400 V Automatic Transfer Switch

Schneider Electric TA16D3L1254TPE TransferPacT automatic transfer switch, 3P, 125 A, 400 V AC, LCD controller, 80-160 A frame.

Rated current
125 A
Rated operational voltage
400 V AC
Display
LCD screen
Description

About the TA16D3L1254TPE

The Schneider Electric TA16D3L1254TPE is a 3-pole TransferPacT automatic transfer switch rated 125 A at 400 V AC, built to change the source of supply between two AC networks without interrupting a standby or life-safety load. It carries a lcd screen on the front for local status and control, and it is intended for uninterrupted-duty changeover in industrial, commercial and healthcare installations within the 80-160 A frame.

Certifications & Standards

  • CE
  • CB
  • CCC
  • IEC 60947-6-1

Selection Notes

The 3-pole TA16D3L1254TPE switches only the phase conductors, so the neutral stays solidly connected between the two sources; pick this execution where both the normal and the standby supply share a common neutral-to-earth bond. Its LCD controller displays source status, the active contact position and alarms locally and is operated from the front push-buttons, which is useful where staff need to read the changeover state without opening the panel. Within the 80-160 A frame, this 125 A setting shares its enclosure footprint with the other current ratings built on the same frame, so the panel cut-out does not change if a different rating from the same frame is specified instead. The 10 kA during 0.1 s short-time withstand current lets it be installed directly downstream of an upstream breaker sized to that let-through level, without extra current-limiting fuses, and the AC-33B utilization category confirms it for uninterrupted-duty source changeover.

Specification

Full specification

58 values · Last verified 30 Oct 2026

Main 12

Range of product TransferPacT
Product or component type Automatic transfer switch
Device application Change source of supply
Poles description 3P
Network type AC
Network frequency 50/60 Hz
Downside connection Screwed
Mounting mode Fixed
Upside connection Screwed
Contact position indicator Yes
[Icm] rated short-circuit making capacity 154 kA with upstream protection circuit breaker 400 V AC at 50 Hz, 20 kA switch-disconnector alone 400 V AC at 50 Hz
Suitability for isolation Yes

Complementary 23

Transfer switch class PC
Number of contact position 3
Signal contacts composition 1 NO + 2 NC, 1 NC + 2 NO, 2 NO
Utilization category AC-33B
[Ue] rated operational voltage 400 V AC 50/60 Hz
Control type 4 push-buttons
Operating mode Automatic, Manual
Display type LCD screen
Mounting support Plate, DIN rail
Locking options description Padlock in OFF position
Rated duty Uninterrupted
[Ui] rated insulation voltage Switch: 800 V, Controller: 500 V
[Uimp] rated impulse withstand voltage Switch: 8 kV, Controller: 6 kV
[Ie] rated operational current 125 A
Mechanical interlocking With mechanical interlocking
Mechanical durability 10000 cycles
Connection pitch 30 mm
[Icw] rated short-time withstand current 10 kA during 0.1 s
Height 164 mm
Width 351 mm
Depth 95 mm
Net weight 5.6 kg
[Ith] conventional free air thermal current 125 A at 60 °C

Environment 6

Standards IEC 60947-6-1
Product certifications CE, CB, CCC
IP degree of protection Front face: IP40 auto mode, Inside the enclosure: IP20 manual mode
Ambient air temperature for operation -25…70 °C
Ambient air temperature for storage -40…85 °C
Pollution degree 3
Show all 58 specifications ↓ Show less ↑17 more values in Identification, Contractual warranty, Logistics.

Identification 6

Part number TA16D3L1254TPE
Brand Schneider Electric
Condition New, factory sealed
Source Schneider Electric and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production

Contractual warranty 1

Warranty (in months) 18

Logistics 10

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 29.000 cm
Package 1 Width 38.000 cm
Package 1 Length 58.000 cm
Package 1 Weight 7.175 kg
Shipping weight 5.6 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for TA16D3L1254TPE

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • CE
  • CCC
  • IEC 60947-6-1
Quick answers

Questions about the TA16D3L1254TPE

What is the rated current of TA16D3L1254TPE?

The rated current of TA16D3L1254TPE is 125 A.

Which supply voltage is TA16D3L1254TPE rated for?

The rated operational voltage of TA16D3L1254TPE is 400 V AC.

What is the HS code of TA16D3L1254TPE for customs?

The tariff (HS) code on file for TA16D3L1254TPE is 853650.

Where does TA16D3L1254TPE ship from, and how fast?

TA16D3L1254TPE ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
